12M Hydraulic Platform Truck

12M Hydraulic Platform Truck photo-1
US$ 15,000 - 24,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Transmission Type:
Manual
Condition:
New
Emission Standard:
Euro 3
Payment & Shipping
Payment Methods:
Port of Shipment:
any port in china
Delivery Detail:
Delivery time depends on order quantity.
Transmission Type Manual
Condition New
Emission Standard Euro 3
Fuel Type Diesel
Dimensions (L x W x H) (mm) 6720*1990*3150
Place of Origin Hubei, China
Brand Name jiangte
Model Number JDF5050JGK

Specifications

12M hydraulic platform truck
1.High Quality Chassis, competitive prices
2.Good service

 12M hydraulic platform truck



1.We are professional manufacturers to do the special vehicles . We are supply all brands of special truck , north benz(beiben) , Faw , Foton , Shaanxi ,Sinotruck , Jac , Jmc , Isuzu ,Dongfeng all available .

2.the drive type could be 4x2 , 4x4 , 6x2 , 6x4 , 6x6 , 8x4

3.We can provide LHD (left hand drive) or RHD (right hand drive) vehicles .

 Product advantage:

1. work platform truck     Factory export department directly sale

 2.Export experience more than 12 years

 3.Cheap / competitive price, high quality ,you get more than your paid

 4.With CCC, ISO , BV approved

 5. The heart of the service, rational design

12M hydraulic platform truck



Product parameters:

Product model

  aerial platform truck for good sale

Product parameters

Total mass(Kg)

6595

Rated weight(Kg)

 /

Curb weight(Kg)

 6069

Overall dimension(mm)

  6720*1990*3150

Carriage dimensions (mm)

 /



Chassis parameters

Chassis model

EQ10603HWRY

Fuel type

 Diesel

Emission standard

 Euro 3



Engine parameters

Engine model

YC4KH1

Manufacturer

YUCHAI

Displacement(ml)

 3815

Power(HP)

95



Main Parameters



Rated person of Cab

 2

Number of axles

 2

Wheelbase(mm)

 3360

Axle load(Kg)

  2005/4720

Tires No.

 6

Tyre size

7.00-16 14PR

Max. speed(Km/h)

 95

Approach angle

/Departure angle (°)

 24/13

Front overhang

/Rear overhang (mm)

  1015/1975

Front track/Rear track(mm)

 1505/1425

12M hydraulic platform truck

12M hydraulic platform truck12M hydraulic platform truck

12M hydraulic platform truck

12M hydraulic platform truck12M hydraulic platform truck



Main Product :



We are professional manufacturer for many kind of special trucks .



12M hydraulic platform truck



 WORKSHOP AND CERTIFICATION :12M hydraulic platform truck12M hydraulic platform truck

12M hydraulic platform truck

12M hydraulic platform truck
