14M High Rise Work Platfrom With JMC Truck

US$ 20,000 - 100,000 MOQ: 1 Set

Key Specifications

Transmission Type:

Manual

Condition:

New

Emission Standard:

Euro 4

Hubei Jiangnan Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in China

Delivery Detail:

Delivery time depends on order quantity.

Transmission Type Manual

Condition New

Emission Standard Euro 4

Fuel Type Diesel

Dimensions (L x W x H) (mm) 7150*1990*2995

Place of Origin Hubei, China

Brand Name JDF

Model Number JDF5052JGKJ4

Specifications

1,Most famous chassis.
2,ISO9001-9002.Quality Standard. CCC approved.
3,High quality.
4,fast delivery time.

JMC 14m Aerial working truck

Contact Information Hot line( 0086-18727938399 Fax: 0086-0722-3330262
Basic Information
Vehicle name		Aerial working truck		Chassis:			JX1060TSG24
Outline size(L×W×H) (mm)		715019902995		Cargo inline size(L×W×H)(mm):			/
Rating mass(kg)		/		Empty mass(Kg):			4475
Full mass(kg)		4800		Emission standard			Euro 4
Engine Information
Model		JX493ZLQ4		Type		6Cylinder Diesel engine
Power/displacement(KW/ML)		80(109HP)/2771		Manufacture		/
Chassis Information
Wheelbase(mm):		3360			Axle load(kg) F/R	1940/3895
Tire		7.00R16LT			Max speed (km/h):	100
Front suspension(mm)		1015			Rear suspension(mm)	1475
Front track(mm)		1385			Rear track(mm)	1425
Approach angel(°)		27			Departure angle(°)	18.5
Steering		Steering			Brake	Air brake
Cabin(Numbers of person)		2+3/3+3
Special function
Max. working height(m)	14m		Max. operation radius(outreach)					7m
Cage capacity(kg)	200		Turning angle°(°)					360°
Trade terms
Quote Lifetime		30days (we promise the quote is effective in the lifetime!)
Payment terms		1. 30% by T/T in advance, 70% by T/T before delivery 2. Letter of credit payment for some countries and regions.
Deliver time		15-30workdays
MOQ		1set
Supply quantity		3,000sets/month
Package		waxing
