China Advance Gearbox (HC600A)
Advantage:
* We supply marine gearbox covers 10-10000hp for single/double engine input
* It is also available for us to design solutions for propulsion system
* All products available approved by ABS,BV,CCS,DNV,GL,LR,NK,etc.,
Certificated of Quality System ISO9001:2000
* Pls contact us for more details
Marine Gearbox HC600A possesses functions of speed reduction, ahead and astern clutching and bearing propeller thrust. It is designed of vertically offset and one-stage transmission, featuring in small in volume and light in weight.
Marine Gearbox HC600A is suitable for passenger, fishing, and various engineering and transport boats.
| Input speed | 1000-2100r/min | ||
| Reduction ratio | 2.00,2.48,3.00 | Trans. capacity | 0.48kw/r/min |
| 3.58 | 0.44kw/r/min | ||
| 3.89 | 0.40kw/r/min | ||
| Control way | Push-and-pull flexible shaft, electrically, pneumatically | ||
| Rated thrust | 90KN | ||
| Center distance | 320mm | ||
| L×W×H | 745*1094*1126mm | ||
| Net weight | 1300kg | ||
| Flywheel | SAE18,16,14 | ||
| Bell housing |
SAE00,0 |
||
Some Other Advance Marine Gearbox for Marine Engines We supply :
Besides,we also have GW series gearbox for low power marine engine.Contact us and know more detail.
