CCS Approved ! Advance Small Marine Gearbox MA100
US$ 500 - 850
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
ADVANCE
Model Number:
marine gearbox-MA100
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or other ports in China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Chinese Advance Boat Gearbox HC138 for SaleUS$ 2,000 - 2,500MOQ: 1 Set -
Good Quality! Advance Marine Reduction Gear Box HC200US$ 2,000 - 2,500MOQ: 1 Set
-
Chinese Advance Marine Gearbox HCA300US$ 2,000 - 2,500MOQ: 1 Set
-
China Advance Small Gear Reduction Boxes HC65NegotiableMOQ: 1 Set
-
Small Advance Marine Gearbox HCD1000 Planetary GearboxUS$ 1500.00 - 1500.00MOQ: 1 Unit
Place of Origin
Zhejiang, China
Brand Name
ADVANCE
Model Number
marine gearbox-MA100
Gearing Arrangement
Other, Planetary, CCS approved ! Advance small marine gearbox MA100
Output Torque
transmission capacity(kw/rpm) 0.009/0.007/0.006
Rated Power
input power range(kw) 13.5-27
Input Speed
1500-3000rpm
Output Speed
reduction ratio(i) 1.60/2.0/2.55/3.11/3.59/3.88
CCS approved ! Advance small marine gearbox MA100
Advantage: novel structure,good connection behavior,maintenance easy,durable in use,large transmitting power,small size and light weight.
Specification:
| MA100 Marine Gearbox | ||||||
| Power/speed(kw/rpm):13.5/1500~27/3000 | ||||||
| Ratio(i) | 1.60 2.0 | 2.55 3.11 | 3.59 3.88 | |||
| Rate(kw/rpm) | 0.009 | 0.007 | 0.006 | |||
| Rated thrust propeller:3KN | Center distance:100mm | |||||
| Bell housing: SAE345 | Flywheel:SAE 11 1/2" 10 7 1/2" | |||||
| L×W×H:236×390×420mm | Net weight:75kg | |||||
| Control type:push-and-pull flexible shaft | ||||||
| Partial engine: 295C,285C,YAMAHA ME125… | ||||||
Some Advance Marine Gearbox for Marine Engines We supply :
Beside,we also have GW series gearbox for low power marine engine.Contact us and know more detail.
