Advance Marine Gearbox HCT800-3 for Marine Engine
US$ 1,000 - 5,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
ADVANCE
Model Number:
HCT800-3
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or other ports in China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Advance Marine Gearbox HCT800-1 for Marine EngineUS$ 1,000 - 5,000MOQ: 1 Piece -
Advance Marine Gearbox HCT600A for Marine EngineUS$ 1,000 - 5,000MOQ: 1 Piece
-
Advance Marine Gearbox HCT600A-1 for Marine EngineUS$ 1,000 - 5,000MOQ: 1 Piece
-
Advance Marine Gearbox HCT400A for Marine EngineUS$ 1,000 - 5,000MOQ: 1 Piece
-
Advance Marine Gearbox HCT400A-1 for Marine EngineUS$ 1,000 - 5,000MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
ADVANCE
Model Number
HCT800-3
Gearing Arrangement
Planetary
Input Speed
800-1800 r/min
Product Description
Marine Gearbox HCT800-3 possesses functions of speed reduction, ahead and astern clutching and bearing propeller thrust. It is designed of vertically offset and two-stage transmission, featuring in compact structure, larger ratio, higher loading capacity and convenient in dis- and reassembly and maintenance.
This product are approved by CCS, BV, GL, LR, ABS, NK, DNV, RS and KR Classification Societies.
Product Application
Marine Gearbox HCT800-3 is suitable for fishing, tug and various engineering boats.
Main Technical Data
| Input speed | 800-1800r/min | ||
| Reduction ratio | 16.56 | Trans. capacity | 0.597kw/r/min |
| 17.95 | 0.551kw/r/min | ||
| 20.2 | 0.491kw/r/min | ||
| Control way | Push-and-pull flexible shaft, electrically, pneumatically | ||
| Rated thrust | 240KN | ||
| Center distance | 736mm | ||
| L×W×H | 1235x1570x1789mm | ||
| Net weight | 4200kg | ||
| Flywheel | SAE21,18,16 | ||
| Bell housing | SAE00,0 | ||
