Weichai WD10/WD12/WP12/WP13 Series Marine Genset Generator 150kw-150kw

Weichai WD10/WD12/WP12/WP13 Series Marine Genset Generator 150kw-150kw thumbnail-1
Weichai WD10/WD12/WP12/WP13 Series Marine Genset Generator 150kw-150kw photo-1
US$ 5,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Weichai
Model Number:
WD10/WD12/WP12/WP13
Contact Supplier Request Quote Chat Now
Xiamen Sitaiqi Industry & Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name Weichai
Model Number WD10/WD12/WP12/WP13
Output Type AC Three Phase
Speed 1500/1800rpm
Frequency 50HZ/60HZ
Rated Voltage 400/230V

Weichai  WD10/WD12/WP12/WP13 Series Marine Genset generator 150kw-150kw



Spectru



Portfolio of WD10/WD12/WP12/WP13 series marine diesel generator set (Marathon generator)


Model Power kW Model of diesel engine Power of diesel engine kW Intake mode LxWxH
mm		 Weight
kg
CCFJ150J-WI 150 WD615.68CD 170 Turbocharged and intercooled 2500 1004 1387 2180
CCFJ180J-WI 180 WD615.46CD    204 Turbocharged and intercooled 2543 1016 1618 2260
CCFJ200J-WI 200/1500 WD618.42CD 235 Turbocharged and intercooled 2540 991 1642 2500
CCFJ220J-WI 220/1500 WD618.42CD 255 Turbocharged and intercooled 2670 991 1642 2500
CCFJ240J-WI 240/1800 WD618.42CD 270 Turbocharged and intercooled 2670 991 1642 2500
CCFJ250J-WI 250/1500 WP12CD290E201 290 Turbocharged and intercooled 2710 1108 1340 2500
CCFJ260J-WI 260/1500 WP12CD290E201 290 Turbocharged and intercooled 2710 1108 1351 2500
CCFJ280J-WI 280/1500 WP13CD385E200 350 Turbocharged and intercooled 2838 1134 1353 2500
CCFJ300J-WI 300/1500 WP13CD385E200 350 Turbocharged and intercooled 2838 1134 1353 2500

Portfolio of WD10/WD12/WP12/WP13 series marine diesel generator set (LEC generator)


Model Power
 kW		 Model of diesel engine Power of diesel engine kW Intake mode LxWxH
mm		 Weight
kg
CCFJ150J-WE 150 WD615.68CD 170 Turbocharged and intercooled 2712 1004 1387 2350
CCFJ180J-WE 180 WD615.46CD 204 Turbocharged and intercooled 2650 1016 1618 2450
CCFJ200J-WE 200/1500 WD618.42CD 235 Turbocharged and intercooled 2646 991 1642 2535
CCFJ220J-WE 220/1500 WD618.42CD 255 Turbocharged and intercooled 2850 991 1642 2535
CCFJ240J-WE 240/1800 WD618.42CD 270 Turbocharged and intercooled 2850 991 1642 2535
CCFJ250J-WE 250/1500 WP12CD290E201 290 Turbocharged and intercooled 2746 1070 1341 2535
CCFJ260J-WE 260/1500 WP12CD290E201 290 Turbocharged and intercooled 2746 1070 1351 2535
CCFJ280J-WE 280/1500 WP13CD385E200 350 Turbocharged and intercooled 2785 1134 1353 2535
CCFJ300J-WE 300/1500 WP13CD385E200 350 Turbocharged and intercooled 2785 1134 1353 2535

Portfolio of WD10/WD12/WP12/WP13 series marine diesel generator set (Stamford generator)


Model Power
 kW		 Model of diesel engine Power of diesel engine kW Intake mode  LxWxH
mm		 Weight
kg
CCFJ150J-WU 150 WD615.68CD 170 Turbocharged and intercooled 2651 1004 1387 2280
CCFJ180J-WU 180 WD615.46CD 204 Turbocharged and intercooled 2543 1016 1618 2330
CCFJ200J-WU 200/1500 WD618.42CD 235 Turbocharged and intercooled 2613 991 1642 2435
CCFJ220J-WU 220/1500 WD618.42CD 255 Turbocharged and intercooled 2610 991 1642 2435
CCFJ240J-WU 240/1800 WD618.42CD 270 Turbocharged and intercooled 2610 991 1642 2435
CCFJ250J-WU 250/1500 WP12CD290E201 290 Turbocharged and intercooled 2855 1133 1353 2435
CCFJ260J-WU 260/1500 WP12CD290E201 290 Turbocharged and intercooled 2855 1133 1353 2435
CCFJ280J-WU 280/1500 WP13CD385E200 350 Turbocharged and intercooled 2870 1134 1353 2435
CCFJ300J-WU 300/1500 WP13CD385E200 350 Turbocharged and intercooled 2870 1134 1353 2435

Portfolio of WD10/WD12/WP12/WP13 series marine diesel generator set (Siemens generator)


Model Power
 kW		 Model of diesel engine Power of diesel engine kW Intake mode LxWxH
mm		 Weight
kg
CCFJ150J-WY 150 WD615.68CD 170 Turbocharged and intercooled 2728 1004 1387 2400
CCFJ180J-WY 180 WD615.46CD 204 Turbocharged and intercooled 2543 1016 1618 2500
CCFJ200J-WY 200/1500 WD618.42CD 235 Turbocharged and intercooled 2540 991 1642 2535
CCFJ220J-WY 220/1500 WD618.42CD 255 Turbocharged and intercooled 2610 991 1642 2535
CCFJ240J-WY 240/1800 WD618.42CD 270 Turbocharged and intercooled 2610 991 1642 2535
CCFJ250J-WY 250/1500 WP12CD290E201 290 Turbocharged and intercooled 2617 1108 1351 2535
CCFJ260J-WY 260/1500 WP12CD290E201 290 Turbocharged and intercooled 2614 1108 1351 2535
CCFJ280J-WY 280/1500 WP13CD385E200 350 Turbocharged and intercooled 2727 1134 1353 2535
CCFJ300J-WY 300/1500 WP13CD385E200 350 Turbocharged and intercooled 2727 1134 1353 2535

The frequency of generator set listed in this table is 50Hz (60Hz generator sets could be provided on request). Power factor is 0.8 (lag). Mode of wiring is three-phase four-wire system.



Parameter



Technical specification of WD10/WD12/WP12/WP13 series marine generator set:



Speed (r/min) 1500/1800
Power (kW) 150/180/200/250/280/300
Pressure (V) 400/440
Frequency (Hz) 50/60
Start mode Electrical start / pneumatic start
Power factor 0.8 (lag)
Cooling mode Dual-circulation water cooling
Speed regulation mode Mechanical/mechanical plus accelerator servo mechanism/electrical







Dimensions

Installation and overall dimension of WD10/WD12/WP12/WP13 series diesel generator set (Marathon generator)


Model A A1 B L L1 W W1 H R D
CCFJ150J-WI 565 240 850 2500 2390 1004 918 1387 8 25
CCFJ180J-WI 565 240 850 2543 2541 1016 910 1618 10 25
CCFJ200J-WI 565 140 850 2540 2540 991 910 1642 8 25
CCFJ220J-WI 565 140 850 2670 2540 991 910 1642 8 25
CCFJ240J-WI 565 140 850 2670 2540 991 910 1642 8 25
CCFJ250J-WI 565 400 850 2710 2508 1108 1000 1341 8 25
CCFJ260J-WI 565 400 850 2710 2508 1108 1000 1351 8 25
CCFJ280J-WI 565 400 850 2838 2598 1134 1000 1353 8 25
CCFJ300J-WI 565 400 850 2838 2598 1134 1000 1353 8 25

Installation and overall dimension of WD10/WD12/WP12/WP13 series diesel generator set (LEC generator)


Model A A1 B L L1 W W1 H R D
CCFJ150J-WE 565 400 850 2712 2454 1004 918 1387 8 25
CCFJ180J-WE 565 160 850 2650 2632 1016 910 1618 10 25
CCFJ200J-WE 600 300 850 2646 2530 991 918 1642 8 25
CCFJ220J-WE 600 300 850 2850 2530 991 918 1642 8 25
CCFJ240J-WE 600 300 850 2850 2530 991 918 1642 8 25
CCFJ250J-WE 565 400 850 2746 2601 1070 1000 1341 8 25
CCFJ260J-WE 565 400 850 2746 2601 1070 1000 1351 8 25
CCFJ280J-WE 565 400 850 2785 2601 1134 1000 1353 8 25
CCFJ300J-WE 565 400 850 2785 2601 1134 1000 1353 8 25

Installation and overall dimension of WD10/WD12/WP12/WP13 series diesel generator set (Siemens generator)


Model A A1 B L L1 W W1 H R D
CCFJ150J-WY 565 400 850 2728 2540 1004 918 1387 8 25
CCFJ180J-WY 565 400 850 2543 2540 1016 918 1618 8 25
CCFJ200J-WU 565 450 850 2613 2601 991 910 1642 8 25
CCFJ220J-WU 565 450 850 2610 2601 991 910 1642 8 25
CCFJ240J-WU 565 450 850 2610 2601 991 910 1642 8 25
CCFJ250J-WU 565 400 850 2855 2448 1133 1000 1353 8 25
CCFJ260J-WU 565 400 850 2855 2448 1133 1000 1353 8 25
CCFJ280J-WU 565 400 850 2870 2538 1134 1000 1353 8 25
CCFJ300J-WU 565 400 850 2870 2613 1134 1000 1353 8 25

Installation and overall dimension of WD10/WD12/WP12/WP13 series diesel generator set (Stamford generator)


Model A A1 B L L1 W W1 H R D
CCFJ150J-WU 565 400 850 2651 2510 1004 918 1387 8 25
CCFJ180J-WU 565 400 850 2543 2510 1016 918 1618 8 25
CCFJ200J-WY 565 400 850 2540 2530 991 918 1642 8 25
CCFJ220J-WY 565 400 850 2610 2530 991 918 1642 8 25
CCFJ240J-WY 565 400 850 2610 2530 991 918 1642 8 25
CCFJ250J-WY 565 400 850 2617 2414 1108 1000 1351 8 25
CCFJ260J-WY 565 400 850 2614 2414 1108 1000 1351 8 25
CCFJ280J-WY 565 400 850 2727 2484 1134 1000 1353 8 25
CCFJ300J-WY 565 400 850 2727 2484 1134 1000 1353 8 25

The frequency of generator set listed in this table is 50Hz (60Hz generator sets could be provided on request). Power factor is 0.8 (lag). Mode of wiring is three-phase four-wire system.



Intruction

Steyr series marine diesel Genset adopts WD10/WD12/WP12/WP13 series diesel engines as its power source with rotation speed of 1,500rpm or 1,800rpm and equipped with famous brand generators such as Marathon, Stanford, Lan Dian, and Siemens. Power ranges from 120kW to 300 kW. CCS, ZY, BV, and RS classification certificates are provided upon request. Configuration Generator: Famous brand generator such as Marathon, Stanford, Lan Dian, Siemens, etc is equipped with insulation class of F Grade and above. Parallel connection function: this series Genset can realize load transfer for more than two units without power off, thus capable of parallel operation. Protection function: the Genset will activate its alarming system when its rotation speed, lub oil pressure, cooling water temperature or lub oil temperature exceeds the limit. Main Features The Genset delivers excellent performance. Steyr series Genset complies with Euro II Emission Standard with great performance due to small size, light weight, low noise, low fuel consumption and high power.
