Weichai M26 Series of Marine Diesel Engine 330Kw-808Kw

Weichai M26 Series of Marine Diesel Engine 330Kw-808Kw thumbnail-1
Weichai M26 Series of Marine Diesel Engine 330Kw-808Kw photo-1
US$ 5,000 - 50,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Engine:
4 Stroke
Engine Capacity:
> 6L
Contact Supplier Request Quote Chat Now
Xiamen Sitaiqi Industry & Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or other ports in China Mainland
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Engine 4 Stroke
Fuel Type Gasoline
Cylinders 6
Engine Position Inboard
Dimensions (L x W x H) (mm) 1870*1095*1410mm
Product Description

M26 series marine diesel engines are the mainstream products manufactured by France-based Moteurs Baudouin, a subsidiary of Weichai Group. With a history of over 100 years, Baudouin series products have fully integrated the advanced technologies in the field of internal combustion engine, featuring compact structure, high power and eco-friendliness. The series products are subdivided into three categories, namely 6-cylinder series, 8-cylinder V type series, and 12-cylinder V type series with a replacement of 16 liters, 21 liters and 32 liters respectively and power ranging from 330kW to 882kW (450-1200PS). Besides, it complies with IMO Tier II emission standard and BV certificate is provided upon request.



Main features:

1. Four valves, steel crankshaft, inter-cooled.

2. Emergency circulation water pipe interface, water-cooled turbocharger.

3. Comprehensive monitoring system: sound & light alarming and emergency stop protection.

4. High reliability: TBO>32,000 hours.

5. Replacement of filter structure without power-off.



Weichai M26 Series of Marine Diesel Engine 330Kw-808Kw

Product Application

 This series are ideally used on inland transport ships, fishing boats and public vessels.



Main Technical Data



Item Unit engine type
6M26C450-18 6M26C500-18 6M26C550-18
intake mode turbocharged and intercooled
number of cylinders 6
bore X stroke 150×150
displacement L 15.9
compression ratio 14
rated power KW 330 368 405
rated speed r/min 1800 1800 1800
min. fuel oil consumption g/(KW.h) ——
fuel consumption @ rated power g/(KW.h) ≤213 ——
fuel consumption @ rated power g/(KW.h) 1.065
cooling mode sea and fresh water duel-circulation cooling system
start mode electric start
net weight kg 1785±50
rotation direction of crankshaft (seen from the free end) clockwise
dimension length mm 1870
width mm 1095
height mm 1410



Item Unit engine type
8M26C650-18 8M26C700-18 8M26C750-18
intake mode turbocharged and intercooled
number of cylinders 8
bore X stroke 150×150
 displacement L 21.2
compression ratio 14
rated power KW 478 515 551
rated speed r/min 1800 1800 1800
min. fuel oil consumption g/(KW.h) ——
fuel consumption @ rated power g/(KW.h) ≤215 ——
lub oil and fuel consumption ratio g/(KW.h) 1.1
cooling mode sea and fresh water duel-circulation cooling system
start mode electric start
net weight kg 2475±50
rotation direction of crankshaft (seen from the free end) C.W.
dimension length mm 1805
width mm 1411
height  mm 1229



Item Unit  engine type
12M26C900-18 12M26C1000-18 12M26C1100-18
intake mode  turbocharged and intercooled
number of cylinders 12
bore X stroke 150×150
 displacement L 31.8
compression ratio 14
rated power KW 662 736 808
rated speed r/min 1800 1800 1800
min. fuel oil consumption g/(KW.h) ——
fuel consumption @ rated power g/(KW.h) ≤209
cooling mode sea and fresh water duel-circulation cooling system
start mode electrical
net weight kg 3400±50
rotation direction of crankshaft (seen from the free end) clockwise
dimension length mm 2433
width mm 1521
height mm 1816
