Weichai-Man L27/38 Series of Marine Diesel Engine 2040Kw-3285Kw

Weichai-Man L27/38 Series of Marine Diesel Engine 2040Kw-3285Kw thumbnail-1
Weichai-Man L27/38 Series of Marine Diesel Engine 2040Kw-3285Kw photo-1
US$ 5,000 - 50,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Engine:
4 Stroke
Engine Capacity:
> 6L
Contact Supplier Request Quote Chat Now
Xiamen Sitaiqi Industry & Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or other ports in China Mainland
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Engine 4 Stroke
Fuel Type Diesel
Cylinders 6
Engine Position Inboard
Dimensions (L x W x H) (mm) 5070*2035*3555mm
Product Description

 After a production agreement reached by Weichai and world No.1 marine diesel engine manufacturer---Germany-based MAN AG, Weichai-MAN L27/38 series marine diesel engines were introduced to China. Adopting the integral rigid design, the series achieve high security. Its cylinder units, which can be easily installed and taken apart, are integrally installed. Adopting the state-of-art turbocharger and dual inter-cooler from MAN AG, this series products pride themselves in their intake performance. What's more, its AT2000 security control system from MAN AG fully ensures its reliability. With the capability of burning MGO, MDO and HFO,  Highly powerful and economic, engines used for main propulsion consist of 6, 7, 8 or 9 cylinders with a rotation speed of 800r/min and power coverage of 2,040-3,285kW (min. fuel oil consumption: 184g/kWh; lub oil consumption <0.8g/kWh).



Weichai-Man L27/38 series have passed the International Association Classification Society Certificates of CCS, ZY, ABS, GL, BV, DNV , RS and  LR.



Weichai-Man L27/38 Series of Marine Diesel Engine 2040Kw-3285Kw

Product Application

 This series engines are well adapted to various working conditions. It is mainly used as the main and auxiliary engines for ships.





Main Technical Data



Item Unit Engine type
6L27
/38		 7L27
/38		 8L27
/38		 9L27
/38
Intake mode   turbocharged and intercooled
number of cylinders   6 7 8 9
bore X stroke   270×380
 displacement L 130.8 152.6 174.4 196.2
compression ratio   15.9
rated speed R
/min		 800 800 800 800
fuel   HFO
/MDO		 MGO HFO
/MDO		 MGO HFO
/MDO		 MGO HFO
/MDO		 MGO
rated power KW 2040 2190 2380 2555 2720 2920 3060 3285
min. fuel oil consumption G
/KWh		 185(HFO/MDO)/186(MGO)
fuel consumption @ rated power G
/KWh		 188 191 188 191 188 191 188 191
cooling mode   high and low tempreture fresh water binary
start mode   air motor
rotation direction of crankshaft (seen from the free end)   clockwise
dimension L mm 5070 5515 5960 6405
W mm 2035 2035 2035 2035
H mm 3555 3687 3687 3687
H* mm 2500 2500 2500 2500
net weight  t 29 32.5 36 39.5



Note: H* is the hoisting height benchmarked at the center of the bent axle.
