Weichai-Man L32/40 Series of Marine Diesel Engine

Weichai-Man L32/40 Series of Marine Diesel Engine thumbnail-1
Weichai-Man L32/40 Series of Marine Diesel Engine photo-1
US$ 5,000 - 50,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Engine:
4 Stroke
Engine Capacity:
> 6L
Contact Supplier Request Quote Chat Now
Xiamen Sitaiqi Industry & Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or other ports in China Mainland
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Engine 4 Stroke
Fuel Type Diesel
Cylinders 6
Engine Position Inboard
Dimensions (L x W x H) (mm) 5940*2630*4010mm
Product Description

 After a production agreement reached by Weichai and world No.1 marine diesel engine manufacturer---Germany-based MAN AG, Weichai-MAN L32/40 series marine diesel engines were introduced to China. Adopting the integral rigid design, the series achieve high security. The cylinder units, which can be easily installed and taken apart, are integrally installed. Adopting the state-of-art turbocharger and dual inter-cooler from MAN AG, this series products pride themselves in their intake performance. What's more, SaCosOne security control system from MAN AG fully ensures its reliability. With the capability of burning MGO, MDO and HFO. Highly powerful and economic, engines used for main propulsion consist of 6, 7, 8 or 9 cylinders with a rotation speed of 750r/min and power coverage of 3,000-4,500kW (min. fuel oil consumption: 182g/kWh; lub oil consumption <0.5g/kWh).



Weichai-Man L32/40 series have passed the International Association Classification Society Certificates of CCS, ZY, ABS, GL, BV, DNV , RS and  LR.



Weichai-Man L32/40 Series of Marine Diesel Engine

Product Application

 This series of engines are well adapted to various working conditions. It is chiefly used as the main and auxiliary engines for ships.

Main Technical Data



Item Unit Engine type
6L32
/40		 7L32
/40		 8L32
/40		 9L32
/40
Intake mode  Turbocharged and intercooled
Number of cylinders 6 7 8 9
Bore X stroke 320×400
 Displacement L 193.02 225.19 257.36 289.53
Compression ratio 15.2
Rated speed r/min 750 750 750 750
Rated power KW 3000 3500 4000 4500
Min. fuel oil consumption g/KWh 182
fuel consumption @ rated power g/KWh 185
cooling mode  low and high tempreture fresh water binary
start mode air motor
rotation direction of crankshaft (seen from the free end) clockwise
dimension L mm 5940 6470 7000 7530
W mm 2630 2630 2715 2715
H mm 4010 4010 4490 4490
H* mm 3460 3460 3460 3460
net weight  t 38 42 47 51
