Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > Weichai WP4/WP6 Series Marine Emergency Genset
Weichai WP4/WP6 Series Marine Emergency Genset
US$ 5,000 - 10,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Weichai
Model Number:
WP4/WP6
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
MACH30G Series Generator Set With High-power and Middle SpeedUS$ 100,000 - 1,000,000MOQ: 1 Unit -
Yuchai NY280 Series High-power Generator Set 1000kw-3000kwUS$ 80,000 - 1,000,000MOQ: 1 Unit
-
Yuchai NY320 Series High-power Generator Set 2875kw-4315kwUS$ 100,000 - 1,000,000MOQ: 1 Unit
-
25kva Single Phase Small Diesel Generator Silent TypeUS$ 600 - 2,800MOQ: 1 Unit
-
KAMA 31.25kva Three Phase Small Diesel Generator Silent TypeUS$ 800 - 3,000MOQ: 1 Acre
Place of Origin
Shandong, China
Brand Name
Weichai
Model Number
WP4/WP6
Frequency
50HZ/60HZ
Rated Power
30KW-120KW
Weichai WP4/WP6 Series Marine Emergency Genset
SPECTRU
Generating set spectrum chart of WP4/WP6 series marine emergency diesel generator set (Marathon generator)
| engine type | Rated power kW | Diesel engine model | Rated power of diesel enginekW | intake mode | Dimension mm | Weight kg | ||
| CCFJ30Y -WJ | 30 | TD226B -4CD1 | 60 | turbocharged | 1871 | 600 | 1546 | 925 |
| CCFJ40Y -WJ | 40 | TD226B -4CD1 | 60 | turbocharged | 1818 | 600 | 1546 | 915 |
| CCFJ50Y -WJ | 50 | TD226B -4CD1 | 60 | turbocharged | 1818 | 600 | 1546 | 915 |
| CCFJ64Y -WJ | 64 | WP90CD -15 | 90 | turbocharged | 2219 | 778 | 1575 | 1450 |
| CCFJ75Y -WJ | 75 | WP120CD -15 | 90 | turbocharged | 2219 | 778 | 1575 | 1450 |
| CCFJ90Y -WJ | 90 | WP120CD -15 | 120 | turbocharged and intercooled | 2480 | 798 | 1627 | 1550 |
| CCFJ100Y -WJ | 100 | WP120CD -15 | 120 | turbocharged and intercooled | 2480 | 798 | 1627 | 1550 |
| CCFJ120Y -WJ | 120 | WP180CD -15 | 132 | turbocharged and intercooled | 2480 | 798 | 1627 | 1600 |
Generating set spectrum chart of WP4/WP6 series marine emergency diesel generator set (Orchid electric generator)
| engine type | Rated power kW | Diesel engine model | Rated power of diesel enginekW | intake mode | Dimension mm | Weight kg | ||
| CCFJ30 Y-WF | 30 | TD226B -4CD1 | 60 | turbocharged | 1946 | 600 | 1546 | 975 |
| CCFJ40 Y-WF | 40 | TD226B -4CD1 | 60 | turbocharged | 1946 | 600 | 1546 | 975 |
| CCFJ50 Y-WF | 50 | TD226B -4CD1 | 60 | turbocharged | 1946 | 600 | 1546 | 975 |
| CCFJ64 Y-WF | 64 | WP90CD -15 | 90 | turbocharged | 2359 | 778 | 1575 | 1500 |
| CCFJ75Y-WF | 75 | WP120CD-15 | 90 | turbocharged | 2359 | 778 | 1575 | 1500 |
| CCFJ90Y-WF | 90 | WP120CD-15 | 120 | turbocharged and intercooled | 2480 | 798 | 1627 | 1600 |
| CCFJ100Y-WF | 100 | WP120CD-15 | 120 | turbocharged and intercooled | 2480 | 798 | 1627 | 1600 |
| CCFJ120Y-WF | 120 | WP180CD-15 | 132 | turbocharged and intercooled | 2567 | 798 | 1627 | 1680 |
Generating set spectrum chart of WP4/WP6 series marine emergency diesel generator set (Stanford generator)
| engine type | Rated power kW | Diesel engine model | Rated power of diesel enginekW | intake mode | Dimension mm | Weight kg | ||
| CCFJ30Y -WV | 30 | TD226B -4CD1 | 60 | turbocharged | 1947 | 600 | 1546 | 961 |
| CCFJ40Y -WV | 40 | TD226B -4CD1 | 60 | turbocharged | 1947 | 600 | 1546 | 920 |
| CCFJ50Y -WV | 50 | TD226B -4CD1 | 60 | turbocharged | 1947 | 600 | 1546 | 920 |
| CCFJ64Y -WV | 64 | WP90CD -15 | 90 | turbocharged | 2354 | 798 | 1575 | 1500 |
| CCFJ75Y -WV | 75 | WP120CD -15 | 90 | turbocharged | 2354 | 798 | 1575 | 1500 |
| CCFJ90Y -WV | 90 | WP120CD -15 | 120 | turbocharged and intercooled | 2580 | 798 | 1627 | 1580 |
| CCFJ100Y -WV | 100 | WP120CD -15 | 120 | turbocharged and intercooled | 2580 | 798 | 1627 | 1600 |
| CCFJ120Y -WV | 120 | WP180CD -15 | 132 | turbocharged and intercooled | 2580 | 798 | 1627 | 1620 |
Generating set spectrum chart of WP4/WP6 series marine emergency diesel generator set (Siemens generator)
| engine type | Rated power kW | Diesel engine model | Rated power of diesel enginekW | intake mode | Dimension mm | Weight kg | ||
| CCFJ30Y -WZ | 30 | TD226B -4CD1 | 40 | turbocharged | 2250 | 600 | 1546 | 965 |
| CCFJ40Y -WZ | 40 | TD226B -4CD1 | 60 | turbocharged | 2250 | 600 | 1546 | 1000 |
| CCFJ50Y -WZ | 50 | TD226B -4CD1 | 60 | turbocharged | 2416 | 778 | 1575 | 1520 |
| CCFJ64Y -WZ | 64 | WP90CD -15 | 90 | turbocharged | 2416 | 778 | 1575 | 1560 |
| CCFJ75Y -WZ | 75 | WP120CD -15 | 90 | turbocharged | 2581 | 798 | 1627 | 1700 |
| CCFJ90Y -WZ | 90 | WP120CD -15 | 120 | turbocharged and intercooled | 2581 | 798 | 1627 | 1750 |
| CCFJ100Y -WZ | 100 | WP120CD -15 | 120 | turbocharged and intercooled | 2581 | 798 | 1627 | 1820 |
| CCFJ120Y -WZ | 120 | WP180CD -15 | 132 | turbocharged and intercooled | 2050 | 600 | 1546 | 930 |
Dimensions
Installation dimension of WP4/WP6 series marine emergency diesel generator set (Marathon generator)
| Model | A | A1 | B | L | L1 | W | H | R | D |
| CCFJ30Y-WJ | 700 | 247 | 550 | 1871 | 1832 | 600 | 1546 | 6 | 19 |
| CCFJ40Y-WJ | 700 | 300 | 550 | 1818 | 1818 | 600 | 1546 | 6 | 19 |
| CCFJ50Y-WJ | 700 | 300 | 550 | 1818 | 1818 | 600 | 1546 | 6 | 19 |
| CCFJ64Y-WJ | 600 | 240 | 722 | 2219 | 2219 | 778 | 1575 | 8 | 19 |
| CCFJ75Y-WJ | 600 | 240 | 722 | 2219 | 2219 | 778 | 1575 | 8 | 19 |
| CCFJ90Y-WJ | 600 | 300 | 742 | 2480 | 2480 | 798 | 1627 | 8 | 19 |
| CCFJ100Y-WJ | 600 | 300 | 742 | 2480 | 2480 | 798 | 1627 | 8 | 19 |
| CCFJ120Y-WJ | 600 | 300 | 742 | 2480 | 2194 | 798 | 1627 | 8 | 19 |
Installation dimension of WP4/WP6 series marine emergency diesel generator set (Orchid electric generator)
| Model | A | A1 | B | L | L1 | W | H | R | D |
| CCFJ30Y-WF | 700 | 246 | 550 | 1946 | 1946 | 600 | 1546 | 6 | 19 |
| CCFJ40Y-WF | 700 | 246 | 550 | 1946 | 1946 | 600 | 1546 | 6 | 19 |
| CCFJ50Y-WF | 700 | 246 | 550 | 1946 | 1946 | 600 | 1546 | 6 | 19 |
| CCFJ64Y-WF | 600 | 240 | 722 | 2359 | 2359 | 778 | 1575 | 8 | 19 |
| CCFJ75Y-WF | 600 | 240 | 722 | 2359 | 2359 | 778 | 1575 | 8 | 19 |
| CCFJ90Y-WF | 600 | 300 | 742 | 2480 | 2480 | 798 | 1627 | 8 | 19 |
| CCFJ100Y-WF | 600 | 300 | 742 | 2480 | 2480 | 798 | 1627 | 8 | 19 |
| CCFJ120Y-WF | 600 | 300 | 742 | 2567 | 2530 | 798 | 1627 | 8 | 19 |
Installation dimension of WP4/WP6 series marine emergency diesel generator set (Stanford generator)
| Model | A | A1 | B | L | L1 | W | H | R | D |
| CCFJ30Y-WV | 700 | 247 | 550 | 1947 | 1947 | 600 | 1546 | 6 | 19 |
| CCFJ40Y-WV | 700 | 247 | 550 | 1947 | 1947 | 600 | 1546 | 6 | 19 |
| CCFJ50Y-WV | 700 | 247 | 550 | 1947 | 1947 | 600 | 1546 | 6 | 19 |
| CCFJ64Y-WV | 600 | 280 | 742 | 2354 | 2354 | 798 | 1575 | 8 | 19 |
| CCFJ75Y-WV | 600 | 280 | 742 | 2354 | 2354 | 798 | 1575 | 8 | 19 |
| CCFJ90Y-WV | 600 | 300 | 742 | 2580 | 2580 | 798 | 1627 | 8 | 19 |
| CCFJ100Y-WV | 600 | 300 | 742 | 2580 | 2580 | 798 | 1627 | 8 | 19 |
| CCFJ120Y-WV | 600 | 300 | 742 | 2580 | 2580 | 798 | 1627 | 8 | 19 |
Installation dimension of WP4/WP6 series marine emergency diesel generator set (Siemens generator)
| Model | A | A1 | B | L | L1 | W | H | R | D |
| CCFJ30Y-WZ | 700 | 300 | 550 | 2050 | 2050 | 600 | 1546 | 6 | 19 |
| CCFJ40Y-WZ | 700 | 300 | 550 | 2250 | 2250 | 600 | 1546 | 6 | 19 |
| CCFJ50Y-WZ | 700 | 300 | 550 | 2250 | 2250 | 600 | 1546 | 6 | 19 |
| CCFJ64Y-WZ | 600 | 280 | 722 | 2416 | 2359 | 778 | 1575 | 8 | 19 |
| CCFJ75Y-WZ | 600 | 280 | 722 | 2416 | 2359 | 778 | 1575 | 8 | 19 |
| CCFJ90Y-WZ | 600 | 100 | 742 | 2581 | 2581 | 798 | 1627 | 10 | 19 |
| CCFJ100Y-WZ | 600 | 100 | 742 | 2581 | 2581 | 798 | 1627 | 10 | 19 |
| CCFJ120Y-WZ | 600 | 100 | 742 | 2581 | 2581 | 798 | 1627 | 10 | 19 |
Note: 226B/WP4/WP6 marine emergency diesel generator set silencer diameter of outlet: 30--50kWφ68, 64--75kWφ72, 90-120kWφ96. The table size is subject to 1500rpm/400V generator sets.
