168T injection moulding machine manufacturer
Big tie bar space and shot weight capacity;
World famous component parts;
Competitive price and quality guarantee.
It can be widely used to produce all kinds of plastics parts, with characters of high efficiency and good performance.
Template structure of the high-rigidity design, both T-slots and conventional screw holes make mold is easy to install;
Parameters of this injection molding machine as below;
| Parameter | Unit | Parameter Value (SSF1680-K5) | ||
| Screw diameter | mm | A | B | C |
| 42 | 45 | 50 | ||
| Screw L/D ratio | L/D | 23.6 | 22 | 19.8 |
| shot volumn (theoretical) | Cm3 | 311 | 357 | 441 |
| injection weight(PS) | g | 283 | 325 | 402 |
| injection rate | g/s | 138 | 160 | 196 |
| injection pressure | Mpa | 203 | 177 | 143 |
| screw speed | rmp | 180 | ||
| clamp force | KN | 1680 | ||
| open stroke | mm | 435 | ||
| distance between tie bars (W*H) | mm | 460*460 | ||
| max mould thickness | mm | 520 | ||
| min mould thickness | mm | 180 | ||
| ejector stroke | mm | 135 | ||
| ejector force | KN | 50 | ||
| ejector number | PC | 5 | ||
| dia of mould location hole | mm | 125 | ||
| max pump pressure | Mpa | 16 | ||
| pump motor power | KW | 18.5 | ||
| heating power | KW | 12.3 | ||
| machine dimension | m | 5.13*1.45*2.12 | ||
| machine weight | T | 6 | ||
| oil tank capacity | L | 300 | ||
Standard features;
Double-cylinder balanced injection system;
Multi-stage pressure &speed injection;
Back pressure adjustment device;
Low pressure mold protection;
Single hydraulic core pulling and inserting;
Multiple hydraulic ejector knock-out;
Mechanical, electrical safety device;
Auto lubrication system;
Hydraulic pressure full proportional control;
Computer control system;
Molding data memory system;
Automatic mould adjust function.
Optional auxiliary
Robot system
Hopper dryer
Auto loader
Hopper Magnet
Mold clamps
Water cooler
Plastic dehumidizer
Mold temperature controller
Oil temperature controller
Oil bypass filter
Spare parts;
1.Nozzle
2.Lubricate oil
3.Seal rings(5pcs)
4. Tool box
5. Other tools such as spanner, straight screwdrivers;
6. Crash pad
We manufacture injection molding machine strictly follow ISO9001:2008 quality requirements, CE also oprional.
If you have any query about our injection molding machine, just contact me at any time Alexis Liao Mobile photo:+8613806673276(whats app&we chat ID)
QQ:1159033100
