2015 Graph/Vinyl/Sticker/Paper USB Cutting Plotter

2015 Graph/Vinyl/Sticker/Paper USB Cutting Plotter thumbnail-1
2015 Graph/Vinyl/Sticker/Paper USB Cutting Plotter photo-1
US$ 400 - 600 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Die-cutting Machine
Computerized:
Yes
Contact Supplier Request Quote Chat Now
Guangzhou Toyo Advertisement Material Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou huangpu
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Die-cutting Machine
Computerized Yes
Place of Origin Guangdong, China
Brand Name TOYO
Model Number TH 1300
Voltage 220V
Dimension(L*W*H) 1480*265*265mm
Weight 40kg
Certification CE
Warranty 1
After-sales Service Provided Engineers available to service machinery overseas







Product Description

 Specification

Cutting plotter type

TH740

Kuco TH1300

leg



Vertical feeding horse



mainboard

32 bit CPU, 4 MB CACHE memory at a high speed

Control panel

Large touch screen and 11 key light touch membrane keyboard

drive

Dominant twin shaft torque motor, subdivide microstep driver

Feed paper mathod

               Drum high-precision steel shaft

Location mode

Margin system, setting arbitrary origin

Width of Platform

740mm

1300mm

biggest cutting width

635mm

1205mm

Cutting maximum speed

500mm/s

Max cutter length

50000mm





Cutter pressure

0-1000g(Digital Frequency Control )

Mechanical Precision

0.05mm

Accuracy of

<±0.1mm

Type of cutting tools

MIMAKI import





Drawing command

DM-PL/HP-GL (automatic identification)

port

Stander RS232(string)/USB2.0/SD card

Power supply

AC110V /220V±10%,50Hz

comsupction

<100W

<120W

Operating enviroment

tempreture:+5-+35,related humidity30%-70%

Package size

1045*330*335

1582*330*440

weight

18KG

35KG



2015 Graph/Vinyl/Sticker/Paper USB Cutting Plotter2015 Graph/Vinyl/Sticker/Paper USB Cutting Plotter



Features:



1. More Interface: USB, SD card, serial Port,(WIFI Blue tooth Optional)



2.CE Certification,ISO9001 Quality Certification.



3.High-precision Steel Axes: Guarantee the tolerances



4. 32-bit ARM7 CUP,4MB, High-speed CACHE memory.:can repeat the words or images for 0-500 times(Repeat Function)



5.Noise less than 60DB(low Noise, smooth cutting)



6.Our control panel: 11 membrane and 3.0 LCD touching screen,and have 5 kinds of backlight for select.



7.Supper cutting pressure: 0-1000G,can cut supper thickness materials,like reflective film



8. our machine can cut 2mm words and have the function of contour cut



9. Support Mac OS/Windows Windows XP/Vista.



10. Support Artcut,Flexi Sign 10.0,signcut,CAD,CDR,Adobe Illustrator etc



11.Warranty ---Gurrantee the mainboard for1  year and change a new one if mainboard has any

problems within 1 year.



12.Order Gift---Send 1 Pro Artcut software and 10 cutting blades as a gift



2015 Graph/Vinyl/Sticker/Paper USB Cutting Plotter



Usage:

1.Cut artwork created by yourself , such as sticker,, logos and labels made from vinyl or iron-on material;

2. Can be used to make stickers, transfers, POP signs and graphics, shop signs, window signs logos and graphics;





Packaging & Shipping



It is packed in the Standard Carton, put together with install cables, a set of software, cutting blades.



Company Information

Our office is located in Guangzhou. We have our own factory and technician group. We have



passed CE certification and ISO9000 certification. With the main business of  Advertising trade,



.we entered the international market.  We have gained a high reputation in China as well as some



overseas areas, like turkey, India, Thailand, Indonesia, Brazil, Kenya, Zambia, Dubai, Australia,



Mexico and so on.







FAQ

Guarantee and after sales service:



1) The machine guarantee is 1 year;



2) 24hours technical support by email or remote control-TeamViewer or calling;



3)English version manual and operation video CD disc
