Home > Electrical & Electronics > Passive Components > Capacitor > Full Plastic Explosion-proof Operating Post

Full Plastic Explosion-proof Operating Post

US$ 90.77 - 420 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Model Number:

0242

Contact Supplier Request Quote Chat Now

CZ Explosion-Proof Electric Appliances Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name CZ

Model Number 0242

Specifications

Various mounting ways
Flexible configure
IP65
Special vertical foot tray
Stainless steel protection cover

Main technical data:

Ex mark: Ex edCT6     DIP A21 TA,T6
Intended use: Can be used in zone 1 and zone 2
                       Can be used in zone 21 and zone 22
Ambient temperature use: -40≤Ta≤55
Degree of protection: IP65
Rated voltage: max 380V
Rated current: max 16A
Terminals: 2×2.5mm²
PE terminals: 2×4mm²
Material of enclosure: Glass fibre reinforced polyester (SMC) of static resistance
Cable entry: Standard configure:
                    Pendant type: 1×M32 , Cable outside diameter: Φ12 ~ 21mm
                    Vertical type: one stopping plug 1×M32

For the series full plastic explosion-proof operating post three various size enclosures can be selected: has 1 up to 9 mounting position for the board front type explosion-proof components. The enclosure is made of glass fiber reinforced polyester of static resistance. It is impact resistant and is able to subject to the inverse industrial operating conditions. Concave-convex joint is designed between the cover and the body to mount an airfoam silicone bar, which secure degree of protection IP65.

The mounting way of the operating post is pendent, vertical and pipe type. The foot tray used for vertical type and stainless steel water proof cover is available. The built-in explosion-proof component module is mounted on the 35mm standard mounting rail. According to the requirement, the cable entry can be set on the top or bottom. For the full plastic cable gland or metal cable gland.
