Electric Meter Calibrator
- 5 Set / Sets per Month
- As per your request
- T/T
- Acrel Insulation fault locator Accurately locate the circuit where the insulation fault is located AIL150-4
- Acrel Using CAN bus technology, insulation faults of 8 circuits can be located Insulation fault locator AIL150-8
- Acrel current transmitter input AC 0-1/5A output 4-20mA power AC/DC 85-270V BD-AI
- Acrel Active power transmitter AC/DC85-270V 1 Channel analog output BD-3P
- Acrel BD-4E Multi-power digital transmitter 2 channels energy impulse output Rs485 modbus-RTU
- Acrel BD-4EA transmitter 2 channels energy impulse output Rs485 modbus-RTU Multi-power digital
Product Details
Place of Origin: | Henan, China | Brand Name: | SMS | Model Number: | MT3000D |
Display Type: | Digital Only | Measuring Range: | 90-450V | Accuracy Class: | 0.05 |
Supply Voltage: | 90-400V | Operating Temperature: | -25~70 degree | Dimensions: | 340*295*152mm |
Weight: | 3kg |
Product Description
Specifications
1.Certificate: ISO 90012.Accuracy class: 0.05
3.Portable
4.Can test both single-phase & three-phase energy meter
MT3000D Portable Electric Meter Calibrator
Main performance:
1. Newly designed outer case with small size and little weight.
2. Built operation system windows CE. NET. Window operating interface with convenient application.
3. 640x480TFT true color and high precision screen with the wonderful display interface.
4. Built-in large capacity FLASH. The intelligent meter is synchronous loading.
5. DSP high precision technology, multi-electirc parameters measurement synchronously with higher precision.
6. Adopts the latest ARM high performance CPU as the main control unit, the operation speed is faster.
7. The main and subsidiary meter calibration P3/P4 automatic wire checking, constant checking Waveform and the harmonics analysis, demand quantity burden test.
8. Standard RS232 USB interface, the external device such as the bar code, U disk and the portable PC are optional.
9. The GPS and GPRS modular are optional, which can realize the real time data transmission and the GIS information processing.
10. Equipped with wireless model, communication with PDA..
Index:
1. Accuracy: class: 0.05
2. Working voltage: AC80~400V, voltage measurement: 30~400V.
3. Current measurement directly: 0.1A~20A, with clamp: 5A, 500A(100A, 200A, 1000A, A are optional).
4. Measurement accuracy for voltage, current and power: 0.05%.
5. Measurement accuracy for phase: ±0.05°.
6. Measurement accuracy for frequency: 0.01Hz.
7. Power consumption: 15VA.
8. Working enviroment: temperature 25°C~+40°C, humidity: 30~80% RH.
9. Dimension: 340X295X152MM(Length X Width X High).
10. Weight: <=3KGS.
