Small Wheel Loader T915L
* Quanchai 2105 engine,
* ISUZU heavy weight axles,
* Isuzu strengthen axles,
* 8.25-16 tire,
* 2.8m dump height
| Item | T915L |
| Loading Capacity(kg) | 800kg |
| Capacity(m³) | 0.32-0.5m³ |
| Operating weight(kg) | 2800kg |
| Max Tractive Force(Kn) | 25kN |
| Dumping Height(mm) | 2800mm |
| Dumping Distance(mm) | 860mm |
| Grade ability(%) | 35% |
| Min Turning Radius(mm) | 4600mm |
| Dimensions | |
| Length(mm) | 4960mm |
| Width(mm) | 1670mm |
| Height(mm) | 2710mm |
| Wheel base(mm) | 2086mm |
| Tread(mm) | 1350mm |
| The minimum clearance | 345mm |
| Engine | |
| Manufacturer | quanchai |
| Model | QC2105 |
| Power(Kw) | 24kW |
| Transmission | |
| Converter Tyre | Six Axis Transmission |
| Low speed(km/h) | 4/7 Km/h |
| High Speed(km/h) | 16/29 Km/h |
| Service Brake | Hydraulic brake |
| Axles | Isuzu Strengthen Axles |
| Battery | 6-QW-60MF |
| Cabin | Luxury |
| Chair | comfot |
| Steering System | |
| Type | Full Hydraulic steering |
| Steering Angle(°) | ±33° |
| Hydraulic system | |
| System Pressure(Mpa) | 16MPa |
| Total Time(s) | ≤9s |
| Oil Tank | |
| Fuel Tank(L) | 77L |
| Hydraulic Oil Tank(L) | 35L |
| Tyre | |
| Model | 8.25-16 |
| Front tyre Pressure(Mpa) | 0.3MPa |
| Rear tyre Pressure(Mpa) | 0.28MPa |
