Help Center450/750V Rubber Sheathed Cable for Mining
Related Products
-
IEC 60245 Rubber 4* 25mm2 Flexible CableUS$ 0.1 - 50MOQ: 100 Meters -
300/500V Flexible Rubber 25mm2 Copper CableUS$ 0.1 - 50MOQ: 100 Meters
-
Heavy Duty Flexible HO7RN-F Rubber CableUS$ 0.1 - 50MOQ: 100 Meters
-
H07V-R 450/750V PVC Insulation Electrical WireUS$ 0.1 - 50MOQ: 100 Meters
-
Soft Flexible HO5RN-F Rubber CableUS$ 0.1 - 50MOQ: 100 Meters
16mm2/25mm2/50mm2/70mm2/95mm2 Rubber Cable
1). Applications and Working Conditions:
Applications: The product is one of the rubber flexible cable series for mining.apply for power connection wire of mining machine and other analogous equipment whose AC rated voltage is no more than 0.66/1.14KV.
Working Conditions : Temperature of the core for long time use is no more than 65℃,the minimum radius of bend is as 6 times as diameter of the cable.Yellow jacket cable must not be exposed working in the sunshine for a long time.
2). Types and Description:
| Type | Description | Applications |
UC-0.38/0.66 | mining machine rubber sheathed, flexible cable | Rated voltage 0.38/0.66KV mining machine and equipment of power supply connection |
| UCP-0.38/0.66 | mining machine rubber sheathed, shielded, flexible cable | Rated voltage 0.38/0.66KV mining machine and equipment of power supply connection |
| UCP-0.66/1.14 | mining machine rubber sheathed, shielded, flexible cable | Rated voltage 0.66/1.14KV mining machine and equipment to power supply connection |
3). Production Range:
Cable Type | Cable Rated Voltage | Number of cores | Nom. Cross-section Mm2 | ||
| Principal Line | Ground Line | Control Line | |||
| U UP | 1000 | 3 | 1 | 1 | 2.5-70 |
| UY MY | 380/660 | 3 | 1 | - | 4-70 |
| UYP MYP | 380/660 | 3 | 1 | - | 4-70 |
| UYP MYP | 660/1140 | 3 | 1 | - | 4-70 |
| UC | 1000 | 3 | 1 | 2-7 | 10-50 |
| UC MC | 380/660 | 3 | 1 | 3-7 | 16-50 |
| UCP | 1000 | 3 | 1 | 2-7 | 10-50 |
| UCP MCP | 380/660 | 3 | 1 | 3-7 | 16-50 |
| UCPQ | 1140 | 3 | 1 | 3 | 35-70 |
| UCP MCP | 660/1140 | 3 | 1 | 3 | 35-95 |
| UZ UZP MZ MZP | 300/500 | 3 | 1 | 1 | 2.5-4 |
| UYQ MYQ | 300/500 | 2-12 | - | - | 1.0-2.5 |
2 Used in prot agriculture imigation system and illumination
3 Operation condition:
A Rated voltage: Uo/u450/750v
B Max. Permissible continuous operation temperature of conductor 65° C
C The bending radius of cable should not be less than 6 times of diameter of the cable
Standard: GB/T5013-2008
Rated voltage: 450V/750V
Color: Many colors optional or per order
Core: 1core, 2 core, 3 core, 4 core, 5 core, 3core+1core, 3core+2core, 4core+1core...
Cross-insectional area: 1mm2 to 240mm2
| Core and Size mm sq | Stranding (Number of Strand/Strand Diameter | Thickness of Sheath mm | Nominal Overall Diameter mm | Approx. Weight kg/km |
| 1x1.5 | 30x0.25 | 0.8 | 6.0 | 49 |
| 1.2.5 | 50x0.25 | 0.9 | 6.6 | 63 |
| 1x4 | 56x0.30 | 1.0 | 7.6 | 92 |
| 1x6 | 84x0.30 | 1.0 | 8.3 | 115 |
| 1x10 | 80x0.40 | 1.2 | 10.7 | 189 |
| 1x16 | 126x0.40 | 1.2 | 12.0 | 260 |
| 1x25 | 196x0.40 | 1.4 | 14.1 | 369 |
| 1x35 | 276x0.40 | 1.4 | 15.8 | 500 |
| 1x50 | 396x0.40 | 1.6 | 18.3 | 689 |
| 1x70 | 360x0.50 | 1.6 | 20.7 | 918 |
| 1x95 | 475x0.50 | 1.8 | 23.4 | 1202 |
| 1x120 | 608x0.50 | 1.8 | 25.6 | 1489 |
| 1x150 | 756x0.50 | 2.0 | 28.3 | 1824 |
| 1x185 | 925x0.50 | 2.2 | 31.0 | 2202 |
| 1x240 | 1221x0.50 | 2.4 | 34.5 | 2847 |
| 1x300 | 1525x0.50 | 2.6 | 37.7 | 3495 |
| 1x400 | 2013x0.50 | 2.8 | 37.7 | 3495 |
| 1x500 | 1769x0.60 | 3.0 | 37.7 | 3495 |
| 1x630 | 2257x0.60 | 3.0 | 37.7 | 3495 |
Packaging:
Material:
Steel wooden drum (fumigation)
Cable length in each drum: 500m/1000m or as per actual cable length requirements.
Drum size:
As per cable length and container size
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!
Shipping:
Port: Tianjin, or other ports as per your requireents.
Sea freight:
FOB/C&F/CIF quotation are all available.
*For some countries such as Africa countries, middle east countries, our sea freight quotation is much cheaper than clients get from local shipping agency.
Certifications:
