0.6|1kv copper conductor XLPE insulated low voltage 3 core 4core 25mm2 35mm2 50mm2 75mm2 power cable electrical cables
Low voltage cooper conductor XLPE insulated PVC sheathed power cable
1.The applications: Rated voltage (U0/U) 0.6/1kv 8.7/15KV 26/35kV in transmission & transformation line & for water-proofing purpose .
2. Cores: 1~5 cores,3C+1E,4C+1E,3C+2E
3. Product Features:
- No necessary to heat up in advance while installing above 0oC.
- Max. continuous normal operating Temperature: 90oC (PVC Sheathed cable).
- Max. Permissible temperature at short circuit (5s. at longest): 250oC.
- Permissible bending radius: Single core: ≥20(d+D)±5%. Three-core:≥15(d+D)±5%(D is the actual overall diameter of cable, and d is the actual overall diameter of conductor).
4.Model and Data
low voltage cooper conductor XLPE insulated PVC sheathed power cable
| U0/Um(kv) | 1st class | 0.6/1kv | 1.8/3kv | 3.6/6kv | 6/10kv | 8.7/15kv | 12/20kv | 18/30kv | 21/35kv |
| No.of Core | |||||||||
| 1 Core | Sectrion | 1.5-800 | 25-800 | 25-800 | 35-800 | 50-800 | 50-800 | 50-800 | 50-800 |
| area(mm2) | |||||||||
| 2 Core | Section | 1.5-185 | / | / | / | / | / | / | / |
| Area(mm2) | |||||||||
| 3 Core | 1.5-400 | 25-400 | 25-400 | 25-400 | 35-400 | 50-400 | 50-400 | 50-400 | / |
| 4 Core | Section | 2.5-400 | 2.5-400 | / | / | / | / | / | / |
| Area(mm2) |
4 cores:
| Cross Section mm2 | Insulated thickness mm | Sheath thickness mm | Outer diameter mm | Testing Voltage kv | Current loading capacity | |
| in the air | to be laid underground | |||||
| 1.5 | 0.7 | 1.5 | 10.6 | 3.5 | 21 | 25 |
| 2.5 | 0.7 | 1.5 | 11.5 | 3.5 | 28 | 33 |
| 4 | 0.7 | 1.5 | 12.8 | 3.5 | 37 | 44 |
| 6 | 0.7 | 1.5 | 14 | 3.5 | 46 | 54 |
| 10 | 0.7 | 1.5 | 15.9 | 3.5 | 63 | 73 |
| 16 | 0.7 | 2 | 19.1 | 3.5 | 84 | 94 |
| 25 | 0.9 | 2 | 22.7 | 3.5 | 109 | 120 |
| 35 | 0.9 | 2 | 25.4 | 3.5 | 132 | 144 |
| 50 | 1 | 2 | 29 | 3.5 | 159 | 169 |
| 70 | 1.1 | 2 | 32.9 | 3.5 | 195 | 205 |
| 95 | 1.1 | 2.5 | 37.7 | 3.5 | 237 | 245 |
| 120 | 1.2 | 2.5 | 41.6 | 3.5 | 273 | 278 |
| 150 | 1.4 | 3 | 47.6 | 3.5 | 310 | 309 |
| 185 | 1.6 | 3 | 50.6 | 3.5 | 355 | 347 |
| 240 | 1.7 | 3 | 56.4 | 3.5 | 416 | 399 |
| 300 | 1.8 | 3.5 | 62.2 | 3.5 | 473 | 446 |
| 400 | 2 | 3.5 | 68.9 | 3.5 | 512 | 431 |
Hebei Ronghua Wire And Cable Co.,LTD. is a spcialized manufacture of cables.
Welcome Your Visit! Hope to Get in Touch with You! | |
Cable Factory Name |
Hebei Ronghua Wire And Cable Co.,LTD. |
Factory Established in |
Year 1984, 30 Years’ Experience of Producing kinds of Cables |
Factory Location |
Shaheqiao Town, Hejian City, Hebei, China |
Export Office Location |
Aobei Park, Fengshou Road, Shijiazhuang, Hebei, China |
|
Cable Products Type |
Electrical Wires |
Customized Cables per Requirement | |
Overhead Aluminum Aerial Bundle Cable (ABC Cable) | |
Flexible Rubber Cable | |
Mining cable, welding cable, waterproof Submersible pump cable | |
High Temperature Cable, Silicone Rubber Insulated Cable | |
Fire Resistant/ Flame Retardant Power Cable | |
Low Voltage Power Cable and Medium Voltage Power Cable with or without Armour (Armour Type: Steel Tape or Steel Wire) | |
