Universal material testing machine/compression testing machine/tensile testing machine price(YL-1209B)
Product Description:
Universal material testing machine is designed for testing display screens compression resistance under a certain load.
Universal Material Testing Machine has the following advantages : strong functions, easy programming, convenient
operation, low price and so on. It is applied to LCD display manufacturer, R&D of computer
products and testing use. It is popular with manufacturers of display screens,research,develop
and teste computer screen or concerning display screens.
It may test compression resistance of any point in flat surface by adjusting X and Y axle, order Z axle move down by system after position,and keep set time,finish force value and time test graph, then get compression resistance of the specimen from that graph.
Machine Features:
1.Equipped with alternating servo motor, and synchronizing wheel and presion balls screw driving.
2. Accompanied with the digital multi-channel closed loop control system, which apply with the latest measurement and control systems with lots of advanced professional and technical development.
3.Control software can automatically finger out routine data, such as tensile modulus of elasticity, extend rate after rupture, non-proportional extend strength RP0.2, etc. It can realize three close loops control and real time display many testing curves of force-displacement, force-time, and stress-strain. These curves automatically switch.
4.This machine has the following performances: Auto zero, auto gear shifting or no subsection, auto indication, auto save, uni-control or multi-step programmed control, auto stop, auto analysis or assistant manual analysis, batch test, testing result statistic, curve select and over load protection.
5.Machine is multifunctional, and operates easily and reliably.
Specifications:
Capacity |
10N,20N,50N,100N,200N,500N,1KN,2KN,5KN (two capacities is available) |
|
Force Resolution |
1/120,000 |
|
Force Accuracy |
≤+0.5% |
|
Stroke Resolution |
0.005mm |
|
Control Mode |
Computerized LCD screen |
|
Stroke( without grip) |
350 mm |
|
Test Space |
600mm×600mm |
|
Test speed |
0.5~500mm/min |
|
Switchable Force Unit |
kgf,N,Ibf,g,ton,Mpa |
|
Stop Mode |
over-load stop,emergency stop,specimen broken automatic stop, top and bottom limitation automatic stop,automatic reset function |
|
Motor |
Servo motor drive,synchronizing wheel and presion balls screw driving |
|
Power |
400W , 220V , 50/60HZ, 10A |
|
Machine Weight |
80 kg |
|
Machine Dimension |
96×45×97 cm ( W×D×H) |
|
Standard Accessories |
A set of grips, English Operation Manual |
|
Software and test report:
Certificate:
Factory:
