UV Weathering Chamber (Touch Screen Control), Professional High Quality UV light resistance testing machine/UV weathering chamber price/UV weathering test chamber China supplier CE certification, over 15 years experience, one year warranty
Introduction:
This chamber is equipped with fluorescent UV lamp which can completely simulate the UV spectra of sunlight, thus to simulate materials in discoloration and decline of brightness and strength with devices for temperature control and humidification. The UV spectra may cause impairments like cracking, flaking off, pulverization and oxidation, as well as factors such as high temperature, high humidity, condensation and darkening period. etc..
Main Features:
The machine is designed and manufactured in accordance to multiple standard codes, such as ISO 11507/4892-3 and NE 927-6, which serves as the standard of technical indicators.
l UV Chamber is designed for users’ part, with easy-operation and high-security.
l Ordinary tap water is available for QUV original condenser system.
l Water heater is beneath the vessel in stead of being submerged in water, which contributes to convenient-maintenance.
l Water-level controller is set outside the QUV for easier monitoring.
l UV Chamber condensing unit can reach up to 100% humidity by simulating the influence of outdoor humidity.
l Accurate temperature can be measured by blackboard temperature sensor, of which the test results can be repeated.
l Humidity, condensation and water spraying can be tested constantly and circularly.
Parameters:
Standard |
ISO-4892, ASTM-G53, D4587, 4799, BS-27282, SAE-J2020 |
Temp. Range |
RT+10~70°C |
Humidity Range |
75%~95%RH |
Temp. Resolution |
1°C |
Temp. & Humidity Control Method |
Balance adjustment temperature & humidity method |
Light Temp. Range |
50 °C~70°C |
Condensation Temperature Range |
40 °C~60°C |
Blackboard Temperature Measuring Range |
30~80°C |
