Temperature and Humidity Compound Salt Spray Chamber(lower Temperature)

Temperature and Humidity Compound Salt Spray Chamber(lower Temperature) thumbnail-1
Temperature and Humidity Compound Salt Spray Chamber(lower Temperature) photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Yuelian
Model Number:
YL-2209
Contact Supplier Request Quote Chat Now
Guangdong Yuelian Instruments Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name Yuelian
Model Number YL-2209

Specifications

Temperature and humidity Compound Salt Spray Chamber
It is used for imitating natural status in increase imitation test.

Temperature and humidity Compound Salt spray chamber



Temperature and humidity Compound Salt Spray Chamber is used for imitating natural status in increase imitation  test. The imitating condition is harder than status that we usually meet.The tester can simulate and combine the following  status such as: salt smog, dry, humidity, normal temperature, low temperature. It is available to program or conduct the tests independent. The tester is designed for products used in intense changeable environment, such as parts of automobile,

airmaterial, photographic equipment, building materials, electroplate films&coatings and electrical&electronic system etc. It is  suitable to resist to metal electrochemical corrosion.



Model

YL-2209-A

YL-2209-B

YL-2209-C

YL-2209-D

Interior Test Chamber Dimension

(cm)(W×D×H)

90×50×60

120×85×50

160×100×55

200×120×60

Exterior Test Chamber Dimension

(cm)(W×D×H)

146×91×128

220×120×145

260×145×155

300×165×160

Capacity of the chamber(L)

270

480

800

1440

Capacity of the salt water

tank(L)

25

40

Power

AC 220V 50HZ

AC 380V 50HZ

temperature&humidity of the

operating environment

+5°C~ +35°C / <85%RH

air pressure

86~ 106Kpa

Lab. temperature

NSS ACSS           35°C±1°C

CASS              50°C±1°C

Pressure barrel temperature

NSS ACSS           47°C±1°C

CASS                63°C±1°C

Dry test

lab. temperature:40°C-70°C±0.5

Humidity:30%-98±5%RH

Constant temperature&humidity test

lab. temperature:RT°C-70°C±2 (without humidity if the temperature is below the -25°C

temperature cooling time: 35 mins for -70~RT°C

heating up time:

 60 mins for RT-50°C

Temperature accuracy:±2°C/Humidity:30%-98±2%RH

humid heat test

Test Temperature:45°C±2°C

Test Humidity:85%~98%  ±2%RH

salt density

with the density of 5% sodium chloride  solution or to add 0.26 g copper

chloride per litre with 5% sodium chloride.

PH  value

NSS&ACSS:6.5~7.2 /  CASS:3.0~3.2

compressed air pressure

1.00±0.01kgf/cm2

Temp. Stability

less than ±0.5°C

Temp. Uniformity

less than 2. 0°C

Temperature accuracy

less than ±2.0°C

salt fog settlement

1.0~2.0ml/80cm2/h (the average value after collecting 16 hours at least)

material

imported corrosion resisting,aging resistance, high strength  P.V.C  board

heater

corrosion resisting U  type Titanium Tube

temperature load cell

Pt100 platinum resistor

temperature controller

LCD  digital display multicolor touch screen temperature controller

spraying mode

continuous /  batch type spraying (optional)

Demist device

yes

safety device

over temperature protection,earth leakage protection,state caution light etc.



strong wooden case for the tester



Temperature and humidity Compound Salt Spray Chamber(lower temperature)

Workshop

Temperature and humidity Compound Salt Spray Chamber(lower temperature)Temperature and humidity Compound Salt Spray Chamber(lower temperature)Temperature and humidity Compound Salt Spray Chamber(lower temperature)

Factory photos

Temperature and humidity Compound Salt Spray Chamber(lower temperature)Temperature and humidity Compound Salt Spray Chamber(lower temperature)Temperature and humidity Compound Salt Spray Chamber(lower temperature)

Certification

Temperature and humidity Compound Salt Spray Chamber(lower temperature)Temperature and humidity Compound Salt Spray Chamber(lower temperature)Temperature and humidity Compound Salt Spray Chamber(lower temperature)
