Hot air oven/hot air oven specification/price for hot air oven/industrial oven/electrical oven(T25-240)
Porpose:
Hot air oven offers stable and reliable temperature environment of testing space for preheating dryness, qualitative change physics and chemical change requirement.
Physical Structure and Dimension:
1. Internal dimension(w×h×d):1500×1500×1500mm;
2. External dimension: according to the material object;
3. controller lies in right side of the machine, independent from electric cabinet;
4. double doors can open from the middle part, and door lock is level-type;
5. internal material: 304# stainless steel of whole machine, 1.2mm;
6. external material: cold plate stoving varnish treatment, 1.2mm;
7. accessories:a set of cart,divided into 5 levels,material plate: halftone;
8. heat preservation material:imported rock wool,good effect of heat preservation;
9.sealing material: silica gel of resistance to high temperature;
10. without live drive wheels and adjustable fixed foot;
Temperature Control System:
1.temperature control:PID digital instrument (TESHOW instrument in Taiwan),available to automatically calculate, PV/SV simultaneous display, available to set arbitrary temperature value from the normal temperature to the highest temperature by pressing the button to set;
2. timer setting: 0.1 second-999 hours(available to set hours,minutes and seconds)
Temperature counting down, time goes to the moment of cutting heating current(alarm device)
3. heat detector(K)type;
4. output:3-32V;
5. current controller:SSR solid-state relay;
6. heating material: heating pipe of resistance to high temperature;
7. RT-100°C: about 12 minutes;
8. temperature range:normal temperature~150°C.
precision:
1. control precision of meter: ±1°C;
2. displaying analysis:1°C;
3. temperature distribution in the oven: ±4°C.
air supply system:
1. force to blowing-in cycle on two sides, double air channels;
2. motor:tailored version of long axis resistant to high temperature, two group of motor, power:750W / 50Hz;
3. air fan:diverse-wing worm wheel type 10.5 inches;
4. the inner part of the machine is equipped with the plate to adjust the wind direction;
5.equipped with two sets of air intakes in the rear of the machine and two sets of air outlets on the top of the machine.
power:
Voltage: AC 380V three phrases and four lines
Three-phrase electric current: 110 A
Heating power: 22 KW
Total power: 24KW
safety protection system:
1. high temperature protection system: When machine is out of control because of external force,and the temperature exceeds 10 degrees more than the setting temperature, the system will automatically stop heating power supply. Thus it can protect the safety of your products and and the machines.
2. phrase lack protection, rapid insurance, leakage protection.
Specification:
Interior Dimension |
60*80*50cm |
Distribution Accuracy |
±1%(1°C)At-room 100°C |
Control Method |
P.I.D automatic temperature calculation |
Heating Method |
Hot-air circulation system |
Temp. Resolution |
0.1°C units display |
Temp. Range |
Normal temperature +5°C~250°C ( suitable customize 300°C or 500°C) |
Material |
Interior: SUS#304 stainless steel, Exterior: advanced painting |
Accessories |
Double ultra-temperature protection and 2 shelf boards |
Time Setting |
0~9999 hours (minutes) power failure memory type |
Safety Protection |
Independent ultra-temperature protection, safety overload switch |
Power |
AC220V Single phase |
Certificate:
Exhibition:
Factory:
