Programmable Climate Test Chamber (TE Series)

Name: Programmable Climate Test Chamber (TE Series)
Brand: Yuelian
SKU: 112421553
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Yuelian

Model Number:

Guangdong Yuelian Instruments Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Yuelian

Model Number TE

Power Electronic

Usage Other, Climate Test Chamber

Programmable Climate Test Chamber (TE Series)

Purpose:

The Programmable Climate Test Chamber , known as environmental chamber, is designed for testing

the capability of heat-endurance, cold-endurance, dryness-endurance, and humidity-endurance. It is

suitable for the industries of electron, electrical equipment, vehicle, metal, chemistry, building materials,

luggage, adhesion tape, printing, packaging, etc.

Feature:

1. Appearance: high-texture appearance, arc shape body, and matte fringe processing of surface,

planar non-reactive handles, easy operation, safe and reliable.

2. View window: rectangle complex layers of glass view window can be used for observation specimen

when doing testing. With anti-sweat heater unit of the window can prevent water vapor condensing water

droplets, and high-brightness PL fluorescent lamp keeps box lighting.

3. Water supply system: with external connected water supply system, convenient to humidification and

water supply, and automatic recycling and use.

4. Compressor: The compressor circulation system is made in China. it is more effective to remove condenser

tube and capillary lubricants, and it adopts environmental refrigerants (R404,A).

5. Control Mode: adopt smart PID+SSR/SCR forward and inverse two-way synchronization output,

containing advanced slope control logic.

6. Controller: The controller, with multi-stage program editing temperature and humidity,

adopts touch screen made in China.

Specification:

Model	TE-80	TE-150	TE-225	TE-408	TE-800
Interior Dimension (W×H×D)CM	40×50×40	50×60×50	50×75×60	60×85×80	100×100×80
Capacity(L)	80	150	225	408	800
Heating Up Speed	About 3°C/min
Cooling Down Speed	About 1°C/min
Temp. Range	0~150°C, -20~150°C, -40~150°C
Temp. Uniformity	±1°C
Humidity Uniformity	±2.5%
Temp. Stability	±0.1°C
Humidity Stability	±2.5%RH
Humidity Range	20%~98%RH
Programmable Mode	Use high stability platinum temperature resistant materials, LCD Chinese & English touch-screen
Heating System	SUS#304, stainless steel heater
Humidification System	Surface evaporative type, enclose protection of hydropenia, interrupt of power supply and superheat for humidifier.
Dehumidification System	Frozen & latent heat dehumidification method
Cooling System	Adopt unitary type full-closed air-cool refrigeration system
Water Supply System	Circulating water supply system, together with hydropenia warning device
Inner & Outer Material	SUS#304, stainless steel of whole machine
Insulation Material	Rock wool and rigid PU foam thermal insulation
Safety Device	Breaker, compressor overload, ultra-temperature, power failure, temperature limit protection and fault alarm
Temp. & Humidity Regulation	Balance adjustment temperature & humidity method
Standard Accessories	Automatic demist glass window, 2 sets of adjustable upper and lower interlayer, test holes, chamber lamp, mobile wheels
Optional Accessories	Grapher
Power	AC220V/380V±10%,50/60Hz
