ZHF-160 High-speed double heads Tube Filler and Sealer
Key Features
ZHF-160 tube filling & sealing machine is provided with 2 filling heads and a set of double-branch tube feeding system.
Applicable to: plastic composite tubes , aluminum plastic composite tubes and metal tubes(optional)
Optional Devices
1.Externally allocated refrigerator
2.Special-shaped sealing devices (wave type sealing device, arc sealing device, T-shaped punching hole sealing device, metal pipe folding and sealing device)
3.Jacket and barrel heat preservation device
4.Blending device inside the barrel
5.Blowing and sucking type tube cleaning device
6.Nitriding device before and after filling
7.Automatically controlled material feeding device (pump)
8.Finished tube conveyor
Technical Parameters
Operation speed:160/min/(max)
Filling volume:1-300ml
Filling precision: ≤ ±0.5%
Suitable tube length:50-240mm
Suitable tube diameter:10-50mm
Power supply:380Volt, 50Hz (220Volt, 60Hz)
Power of hot-wind generator:3Kw×2
Consumption of compressed air: 1.2 m3
Working pressure:0.6 Mpa
Capacity of hopper:70L
Dimensions:2870×1770×2340mm
