Plastic Tube Filling and Sealing Machine

Plastic Tube Filling and Sealing Machine thumbnail-1
Plastic Tube Filling and Sealing Machine thumbnail-2
Plastic Tube Filling and Sealing Machine photo-1
Plastic Tube Filling and Sealing Machine photo-2
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Chemical, Medical
Packaging Type:
Other, TUBE
Contact Supplier Request Quote Chat Now
Nanjing Rinchen International Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Chemical, Medical
Packaging Type Other, TUBE
Packaging Material Metal
Automatic Grade Automatic
Voltage 380V/220V
Power 5KW
Place of Origin Zhejiang, China
Model Number ZHY-60YP
Dimension(L*W*H) 1950*760*1850mm
Weight 950KG
Certification CE
After-sales Service Provided Engineers available to service machinery overseas



ZHY-60YP Plastic Tube Filling and Sealing Machine



Key Features



1.Compact Design

2.Driving Parts Fully-closed

3.Pneumatic Tube Washing & Feeding

4.Intelligent Temperature Control and Cooling System

5.Easy to Operate and Adjust

6.316L Stainless Steel Contact Parts to meet GMP Standard

7.Safety Interlock Shutdown when Door is Open

8.Overload Protection Provided

9.Automated Working process from Tube Loading to Finished Products Output

10.Automatic Orientation Effected by Photoelectric Induction



Optional Devices

1.Chiller

2.Date Coding Embossing

3.Automatic Tube Feeding Magazine

4.Change Parts



Technical Parameters

Filling volume: 1-250ml/unit (Adjustable)

Filling accuracy: ≤ ±1%

Capacity: 2400-3000unit/hour, Adjustable

Tube diameter: Φ10-50 mm

Tube length: 50-200mm

Hopper volume: 40L

Power: 380V/220V (Optional)

Air pressure: 0.4-0.6 MPa

Equipped motor: 1.1KW

Machine power: 5kw

Inner wind motor: 0.37kw

Convulsions motor: 0.37kw

Dimension: 1950×760×1850(mm)

Weight: About 950 Kg
