Automatic High Speed Double Usage Sealing Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Chemical, Medical
Packaging Type:
Other, TUBE
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Plastic Tube Filling and Sealing MachineNegotiableMOQ: 1 Set -
High Speed Double Usage Filling and SealingNegotiableMOQ: 1 Set
-
Automatic Tube Feeding MachineNegotiableMOQ: 1 Set
-
Ultrasonic and Sealing MachineNegotiableMOQ: 1 Set
-
FLP-6DF PLC Controlled Piston Filling MachineNegotiableMOQ: 1 Set
Condition
New
Application
Chemical, Medical
Packaging Type
Other, TUBE
Packaging Material
Metal
Automatic Grade
Automatic
Voltage
380V/220V
Power
2.2KW
Place of Origin
Zhejiang, China
Model Number
ZHNG-100A
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
ZHNG-100A Series automatic high speed double usage sealing machine
(completion in one machine for plastic tubes, combined tubes and metal tubes)
Key Features
- Compact Design
- two-side folding, three-side folding and saddle-shaped folding of aluminum tubes and metal tubes
- Driving Parts Fully-closed
- Pneumatic Tube Washing & Feeding
- Intelligent Temperature Control and Cooling System
- Easy to Operate and Adjust
- PLC automatic control
- 316L Stainless Steel Contact Parts to meet GMP Standard
- Safety Interlock Shutdown when Door is Open
- Overload Protection Provided
- Automated Working process from Tube Loading to Finished Products Output
- Automatic Orientation Effected by Photoelectric Induction
Optional Devices
- Automatic detection of tube direction inversion
- Automatic cleaning and dust collecting device for the inside of tube
- Tube bottom material feeding form
- Equipped with automatic material temperature control blending system.
- Ultrasonic hopper level automatic detection system.
Technical Parameters
Filling volume |
Metal 1-150ml plastic 1-250ml |
Filling accuracy |
≤ ±1% |
Capacity |
3600-6000unit/hour, Adjustable |
Tube diameter |
Metal Φ10-35 mm plastic Φ10-60mm |
Tube length |
50-240 mm |
Hopper volume |
40L |
Power |
380V/220V (Optional) |
Air pressure |
0.4-0.6 MPa |
Equipped motor |
2.2KW |
