High Speed Roll to Roll Craft Paper Cutting Machine

High Speed Roll to Roll Craft Paper Cutting Machine thumbnail-1
High Speed Roll to Roll Craft Paper Cutting Machine thumbnail-2
High Speed Roll to Roll Craft Paper Cutting Machine thumbnail-3
High Speed Roll to Roll Craft Paper Cutting Machine thumbnail-4
High Speed Roll to Roll Craft Paper Cutting Machine thumbnail-5
High Speed Roll to Roll Craft Paper Cutting Machine thumbnail-6
High Speed Roll to Roll Craft Paper Cutting Machine photo-1
High Speed Roll to Roll Craft Paper Cutting Machine photo-2
High Speed Roll to Roll Craft Paper Cutting Machine photo-3
High Speed Roll to Roll Craft Paper Cutting Machine photo-4
High Speed Roll to Roll Craft Paper Cutting Machine photo-5
High Speed Roll to Roll Craft Paper Cutting Machine photo-6
US$ 9,000 - 25,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Slitting Rewinder
Computerized:
Yes
Contact Supplier Request Quote Chat Now
Ruian Ruihua Printing Packing Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Slitting Rewinder
Computerized Yes
Place of Origin Zhejiang, China
Brand Name JINGDIANRUIHUA
Model Number RH-SLT-1100C
Voltage 220V/380V 50Hz 3Phase
Power(W) 8kw
Dimension(L*W*H) 2000*2350*1350mm
Weight 2800kg
Certification CE for Craft Paper Cutting Machine
Warranty One year guarantee time
After-sales Service Provided Engineers available to service machinery overseas
Product Description



Craft Paper Cutting Machine

Use:

Craft Paper Cutting Machine is used for slitting and rewinding various large rolling materials such as regular paper,cellophane paper, bill paper, double-face adhesive tape, PVC, Al ,foil,weave material, non-woven of cloth, BOPP,OPP,PET etc.





Main Technical Parameters

Model Type

RH-SLT-1100C

Max. Parent Web Width

1100mm

Max. Parent Web Diameter

1000mm

Max. Rewinding Diameter

600mm

Min. Slitting Width

30mm

Thickness Range

Paper in 30-500gsm

Film in 0.008-0.12mm

Max. Speed

300m/min

Unwinding Shaft

3” Pneumatic Air Expanding Shaft

Rewinding Shaft

3” Pneumatic Air Expanding Shaft

Precision

0.15mm

Total Power

8Kw

Voltage

3Phae 4Line 380V 50Hz

Weight

About 2800kgs

Overall Dimension

2000*2350*1350mm



Specifications

  1. Craft Paper Cutting Machine is with PLC control and touch screen, working data can be preset and displayed on the control panel, working automatically.
  2. Craft Paper Cutting Machine is with double frequency inverter motor control, one for material feeding, one for tension control.
  3. Craft Paper Cutting Machine is with double frequency inverter for motor control, stable working and long lifespan.
  4. Craft Paper Cutting Machine is with automatic meter counter for working length tracking, when reached the preset length, machine stop and alarm automatically.
  5. Craft Paper Cutting Machine is with A and B pneumatic shaft structure for rewinding, easy for loading and unloading, and no overlap(rewinding rolls can be easily separated).
  6. Craft Paper Cutting Machine is with 3 sets magnetic brake/clutch for unwind/rewind tension control.
  7. 3 sets automatic tension control system are implanted in PLC, easy operation.
  8. Machine is with photoelectric automatic error correction adjustment system for unwinding to keep accurate roll edge.
  9. Machine is with edge trimming system for waste edge trimming.
  10. Craft Paper Cutting Machine is with automatic pneumatic loading system with 3’’ air expanding shaft for jumbo roll loading, easy operation.
  11. Craft Paper Cutting Machine is with automatic cut when meter reached the preset data.

 High Speed Roll to Roll Craft Paper Cutting Machine



Company Information



High Speed Roll to Roll Craft Paper Cutting MachineHigh Speed Roll to Roll Craft Paper Cutting Machine





Packaging & Shipping



Package&Shipping:

High Speed Roll to Roll Craft Paper Cutting Machine



Our Services







1. Customize is available

2. 24 hours online service

3. After sales service: engineers are available to service overseas

4. In the warranty time, we will provide free parts replacements and maintenance service.

5. Our machine is with whole life technical support.



FAQ



Q: Are you a factory or trading company?

A: We are manufacturer, have our own factory. We not only sell machines, but also provide business solutions for you.

Q: What kind of quality certificate do you have?

A: We have CE certificate, SGS, ISO, etc.

Q: How about the delivery time of machines?

A: Usually, our machines can be delivered within 30 working days.

Q: What’s the payment terms?

A: Usually, we do T/T with 30% deposit, and 70% balance paid before machine delivery. And L/C, western union, etc are also acceptable. Payment terms can be discussed with us.

Q: If come to visit, how can I go to your factory?

A: Welcome your visiting. We are in Ruian, Zhejiang Province, the transportation is convenient. It is about 30-40 min from airport to our factory, and 20min from the train station.





More details, pls contact freely.
