Filter Paper Slitting Machine
Main Technical Parameters
Model |
RH-SUR-1100 |
Max. width of unwinding |
1100mm |
Max. diameter of unwinding |
1400mm |
Max. diameter of rewinding |
500mm |
Min. width of slitting |
30mm |
Unwinding |
Automatic pneumatic loading |
Rewinding Shaft |
2 pieces 3’’(76mm) Air Shafts |
Total power |
12kw |
Weight (approx.) |
3000kg |
Overall dimension (L×W×H ) |
3800×3200×1500(mm) |
Voltage |
3Phase 4Line 380V 50Hz |
Specifications
- Filter Paper Slitting Machine is with Mitsubishi PLC control and HMI.All the parameters are displayed on the monitor. Only material roll diameter and thicknessneedsto be setup, the PLC will give a proper parameters for machine running automatically.
- Filter Paper Slitting Machine is with two sets Inverter Motor with bar code, one for material feeding, the other for tension control.
- Filter Paper Slitting Machine is with two sets Frequency Inverters control the motors. One for material feeding, the other for tension control.
- Filter Paper Slitting Machine is with 3 sets of Magnetic Brake/clutch for the unwind/rewind tension control.
- Three sets of auto tension control system are implanted the PLC, convenience operation.
- All transmission rollers have been dynamic/static balance treated.
- Equipped with emergency switch
- With automatic meter counter. Got to the setup data, machine stops and alarms
- All the electric appliances has been gained the CE certificate.
1. Customize is available |
2. 24 hours online service |
3. After sales service: engineers are available to service overseas |
4. In the warranty time, we will provide free parts replacements and maintenance service. |
5. Our machine is with whole life technical support. |
Q: Are you a factory or trading company? |
A: We are manufacturer, have our own factory. We not only sell machines, but also provide business solutions for you. |
Q: What kind of quality certificate do you have? |
A: We have CE certificate, SGS, ISO, etc. |
Q: How about the delivery time of machines? |
A: Usually, our machines can be delivered within 30 working days. |
Q: What’s the payment terms? |
A: Usually, we do T/T with 30% deposit, and 70% balance paid before machine delivery. And L/C, western union, etc are also acceptable. Payment terms can be discussed with us. |
Q: If come to visit, how can I go to your factory? |
A: Welcome your visiting. We are in Ruian, Zhejiang Province, the transportation is convenient. It is about 30-40 min from airport to our factory, and 20min from the train station. |
More information, pls feel free to contact.
