High Quality Machine High Speed Film Blown Machine
US$ 6,500 - 120,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Film
Plastic Processed:
Other, HDPE,LDPE,LLDPE
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo port/Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mini Blown Film MachineryUS$ 15,000 - 50,000MOQ: 1 Set -
Newest Mini Film Blown Making MachineUS$ 7,000 - 8,000MOQ: 1 Set
-
Hot Shrinkable Blown Film MachineUS$ 10,000 - 50,000MOQ: 1 Set
-
Small Plastic Film Extrusion MachineUS$ 6,000 - 20,000MOQ: 1 Set
-
Food Packing Film Making MachineUS$ 9,000 - 20,000MOQ: 1 Set
Condition
New
Application
Film
Plastic Processed
Other, HDPE,LDPE,LLDPE
Blow Moulding Type
Extrusion Blow Moulding
Automatic
Yes
Place of Origin
Zhejiang, China
Brand Name
JINGDIANRUIHUA
Model Number
minitype blown molding machine SJ-50/FM850
Voltage
220V/380V
Power(W)
28kw
Dimension(L*W*H)
4600*2300*3800mm
Weight
2600kg
Certification
CE/ISO9000 for minitype blown molding machine
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
high speed film blown machine
Use :It is used for blowing the various plastic film of low density polyethylene(LDPE), high density polyethylene(HDPE) and linear low density polyethylene (LLDPE) etc,
Which are widely used for packing food, fruit, garments, textile, barbate bag and vest bag other civil and industrial products, etc and for vest bag.
Characteristics :
The cylinders and the screw stems of model SJ-45-50 extruder are made of high-quality alloy steel with optimum hardness and strong corrosion resistance after precision finishing and nitrogen treatment.
FM-600 auxiliary machine can be freely adjusted within the limits of 700mm according to the technological requirements of different materials, and is fitted with a plug-in plate mechanism for making vest bag.
The double-rolling and double-cutting coiling unit adopts torque motor to keep proper tension and make even and roll-changing easy.
Main technical variables:
| Model | SJ-45/FM650 | SJ-50/FM850 |
| Screw Diameter | 45mm | 50mm |
| Screw Ratio | L/D28:1 | L/D28:1 |
| Screw Speed | 10-100r/min | 10-100r/min |
| Power of Main Motor | 11KW | 15KW |
| Max. Extrusion output | 35kg /h | 50kg /h |
| Max. Folding Width of Film | 600mm | 800mm |
| Single-sided Thickness of Film | 0.006 -0.10mm | 0.006 -0.10mm |
| Lifting Range of Auxiliary Machine | 700mm | 700mm |
| Total Power | 22Kw | 28Kw |
| Weight of Machine | 2200kg | 2600kg |
| Overall Dimensions( L × W × H ) | 4000×2000× 2800mm | 4600×2300× 3800mm |
