Economical Shortwave Infrared Car Spray Booth Paint Booth B-11A
US$ 5,500 - 8,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Power:
9KW
External Size:
7050*5300*3250mm
Internal Size:
6900*3900*2700 MM
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB ZHUHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Car Painting RoomNegotiableMOQ: 1 Set -
Truck Spray Booth Bus Spray Booth Tank Spray Booth Spray Room Paint Booth C-500 (15*5*5M)US$ 1 - 32,000MOQ: 1 Set
-
High Quality Low Price Car/furniture Spray Booth Car Paint Booth Baking Booth C-100US$ 5,500 - 8,000MOQ: 1 Set
-
Spray Booth Paint Booth Baking Booth Spray Room Cabin High Quality Low Price CE Type B-100US$ 1 - 8,000MOQ: 1 Set
-
Spray Booth Bus Spray Booth Car Paint Booth C-400P (8.7*4.2*3.3M, Pit Exhaust)US$ 14,500 - 18,000MOQ: 1 Set
Power
9KW
External Size
7050*5300*3250mm
Internal Size
6900*3900*2700 MM
Voltage
380V/ 3PH/ 50HZ
Certification
CE
Disc Dia.
6.9--3.9--2.7
No Load Speed
970RPM
Place of Origin
Guangdong, China
Brand Name
BaoChang
Model Number
B-11A
Spray booth used car spray booth car paint booth baking booth cabin spray room mixing room prep room
| Packing size: 17CBM. 1*40HQ can load 4sets. | ||
| Production time: Within 10--20days. | ||
| Room body | Dimension | Inside Dimension:L7000×W(4000+1255)×H3505(MM) Outside Dimension:L6900×W3900×H2700(MM) |
| Wall Panels | Total thickness of EPS and powder-painted steel plate wall is 50MM. Powder-painted steel plate is 0.376MM thickness. | |
| Basement and floor | Steel assemble, height 330MM, 2lines grills and 3lines indented/diamond plates. Put whole metal basement underground | |
| Driving ramp | 2PCS diamond plate 600MM width for PC. | |
| Personal door | 1-fold with sight window, pressure lock, size: 680×2000(W×H). | |
| Main door | 3-fold with sight windows, door without aluminum frame, size:3000×2700 (W×H) | |
| Heating system | Frame | Sheet metal forming with powder spray process,inside galvanized board and fire-resistance material,outside white color plate |
| Intake fan | 1set 7.5KW European type professional turbo fan, air capacity: 25000M³/H*2PCS, full pressure 800Pa, turning speed: 970RPM. | |
| Exhaust fan | Optional. | |
| Exhaust pipe | 4M straight pipe with elbows. | |
| Exhaust vent control damper | 1SET, manual VCD | |
| Smoke venting pipe | 4M straight pipe with elbows. | |
| Air damper | Cylinder and connecting rod driving system to transfer spray to baking paint freely | |
| Heating | Shortwave infrared heating system, 10units*3pcs*1W. Every pc tube using life 5000--7000hours. | |
| Filter system | Ceiling filter | 6SETS filter; holding net installation model; Holder is made by section steel and with surface powder spray treatment. air filter efficiency:≥95% |
| Floor filter | 2SETS, installed horizontally | |
| Prefilter | 2SETS. | |
| Lighting system | Ceiling light | 8UNITS×3PCS×28W=24PCS×28W, new technology T5 LED tube, every PC can be equip to a normal T8 60W PC lighting bright. Room illumination≥1000LUX. |
| Side light | Optional. | |
| Control system | Electric cabinet | Main components imported are good quality; with overheat, overload, phase-absence protecting; timer, spraying, baking, emergency stop, failure warning, hour meter, motor starts directly. |
| Constant temperature spraying | With constant temperature spraying paint function | |
| Main power | 9KW, 3PH, 380V, 50Hz | |
