Help CenterWire Rope Electric Hoist
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Delhi, India
Brand Name:
ABM
Payment & Shipping
Payment Methods:
Port of Shipment:
New Delhi
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Delhi, India
Brand Name
ABM
Model Number
ABM-MH-6320
Power Source
Hand Chain
Sling Type
Wire Rope
Warranty
1 Year Warranty Against any manufacturing defect
Specifications
Wire Rope Electric HoistDESIGN
- "ABM" Electric Wire Rope Hoists are designed as per IS : 3938 - 1983 and are suitable for medium and heavy duty applications.
CONSTRUCTION
- "ABM" Hoist have a unique modular construction which makes them an ideal choice since each sub assembly is easily accessible individually thus reducing the time and cost involved in the maintenance.
FRAME
- The main plates of tested quality steel are welded / bolted to form very rugged frame.
ROPE DRUM
- Rope Drum is fabricated out of mild steel or seamless tube and is machined and grooved in accordance with IS : 3838 to accommodate full length of Wire rope in one layer.
GEAR BOX
- Totally enclosed, Immersed oil lubricated gear box houses the gear machined out of EN-9 / EN-24 steel and teethed on precision Hobbing machines.
MOTORS
- Hoist duty 415 V, 50 Hz, 3 Phase, A.C., Sqirrel Cage motors with 40% CDF 'B' class insulation and of ample rating and standard make.
HOOK
- Conforming to IS : 8610 Free to rotate & Swivel.
BRAKE
- Instant action "FAIL TO SAFE" Electro Magnetic auto manual DSIC / SHOE Brakes ensures maximum safety and reliability.
WIRE ROPE
- 6 x 37 construction, FMC, best plouging steel tested Wire Rope as per IS : 2266 is used of reputed make like Usha Martin / Ford William etc.
LIMIT SWITCH
- Snap action limit switch to prevent over hoisting and over lowering is provided for maximum safety, make BCH / UNICON.
PANEL
- Totally enclosed, Dust and Vermin Proof-housing components of standards make like SIEMENS / BCH / L & T, provides control at low voltage for safety of the operator.
CONTROL
- From push button pendent station supported with steel link Chain / Wire Rope, operating at 110 Volt.
TECHNICAL DATA
| Item Code No. | Capacity in Kg. |
lift in Mtr. |
H. Speed Mtr / Min |
H Motor H.P. |
C.T. Speed Mtr / Min |
C.T. Motor H.P. |
| ABM-MH-6320 | 25 | 6 | 8 | 0.75 | 15 | 0.25 |
| ABM-MH-6321 | 500 | 6 | 6 | 1.00 | 15 | 0.25 |
| ABM-MH-6322 | 1000 | 6 | 6 | 2.00 | 15 | 0.33 |
| ABM-MH-6323 | 1500 | 6 | 4 | 2.00 | 15 | 0.50 |
| ABM-MH-6324 | 2000 | 6 | 3 | 2.00 | 15 | 0.50 |
| ABM-MH-6325 | 2000 | 6 | 4 | 3.00 | 15 | 0.50 |
| ABM-MH-6326 | 3000 | 6 | 3 | 3.00 | 15 | 0.50 |
| ABM-MH-6327 | 5000 | 6 | 3 | 5.00 | 15 | 0.75 |
| ABM-MH-6328 | 7500 | 6 | 3 | 7.50 | 15 | 1.00 |
| ABM-MH-6329 | 10000 | 6 | 3 | 10.00 | 15 | 1.00 |
| ABM-MH-6330 | 12500 | 6 | 3 | 12.50 | 15 | 1.50 |
| ABM-MH-6321 | 15000 | 6 | 3 | 15.00 | 15 | 1.50 |
