Help Center12PSB-CFuel Injection Pump Test Bench
Related Products
-
GPS916 Fuel Injection Pump Test BenchUS$ 3,800 - 4,500MOQ: 1 Set -
PCM-CH Diesel Fuel Injection Pump Test BenchUS$ 3,800 - 4,500MOQ: 1 Set
-
PCM-C Diesel Fuel Injection Pump Test BenchUS$ 3,800 - 4,500MOQ: 1 Set
-
GPS916 Diesel Fuel Injection Pump Test Bench EquipmentUS$ 3,200 - 4,500MOQ: 1 Set
-
PCM-E Electronic Computer Control Diesel Fuel Injection VE Pump Test Bench Sand Bank Quality ChoiceUS$ 3,000 - 4,000MOQ: 1 Set
Specifications
PCM-C Fuel injection pump test bench1Graduated cylinder: 45CC or 150CC
2 Volume of fuel tank:60L
3 DC.Supply:12/24V
FUNCTIONS
1 Testing 12-cylinder fuel injection pump.
2 Measuring each cylinder delivery at any speed.
3 Checking each cylinder injection timing with static.
4 Checking the sealing injection pump body.
5 Checking the mechanical governor.
6 Checking the pneumatic governor.
7 Checking the vacuum capacity of governor.
8 Checking the pressure compensators(LDA).
9 Measuring the internal pressure of distributor pump body.
10 Testing the electromagnetic valve of distributor pump.
11 Checking transfer pump.
PARAMETERS
1 Output power(KW): 7.5/11/15/18.5/22
2 Power supply:(3-Phase)380V/50Hz (or on request)
3 Height of spindle centers:125mm
4 Graduated cylinder: 45CC or 150CC
5 Volume of fuel tank:60L
6 DC.Supply:12/24V
7 Feeding fuel pressure: Low:0-0.4Mpa High:0-4Mpa
8 Range of speed:+/-4000RPM
9 Air pressure):-50 +300Kpa
