Specifications
Product Name:PCM-CH Diesel Fuel injection pump test benchBrand :xingzhou
PCM-C Diesel Fuel injection pump test bench
FUNCTIONS
1 Testing 12-cylinder fuel injection pump.
2 Measuring each cylinder delivery at any speed.
3 Checking each cylinder injection timing with static.
4 Checking the sealing injection pump body.
5 Checking the mechanical governor.
6 Checking the pneumatic governor.
7 Checking the vacuum capacity of governor.
8 Checking the pressure compensators(LDA).
9 Measuring the internal pressure of distributor pump body.
10 Testing the electromagnetic valve of distributor pump.
11 Checking transfer pump.
PARAMETERS
1.Output power:7.5KW,11KW,15KW
2.Electronical supply:3-Phase380V/50HZ(or on request)
3.Interaxe height:125mm
4.Graduates:45CC,150CC
5.Volume of fuel tank:60L
6.DC.Supply:12/24v
7.Feeding fuel pressure:Low:0-0.4Mpa High:0-4Mpa
8.Range of speed:+/-4000RPM
9.Air pressure):-50 +300Kpa)
10.Control fuel temerature:40+/-2°C
