TXZ-B Injection Pump Test Bench

packing in wooden case

Specifications

TXZ-B injection pump test bench

FUNCTIONS
1 Measurement of each cylinder's delivery at any speed.
2 Checking of each cylinder's injection timing with static.
3 Checking of the sealing of injection pump body.
4 Checking of the advance device in dynamics.
5 Checking of the pneumatic governor.
6 Checking of the mechanical governor.
7 Checking of the vacuum capacity of governor.
8 Measurement of the internal pressure of distributor pump body.
9 Measurement of the reflux delivery of distributor pump.
Testing of the 10 electro-magnetic valve of distributor pump.
11 Checking of the transfer pump.
12 Checking of the LDA.

CHARACTERISTIC
1 Typical product.
2 Inverter driver.
3 Adjusting speed by two ways, hand and preset speed. 7-steps speed preset.
4 High output torque, low fall of rotation speed. Adjusting speed quickly.
5 Speed, strokes, advance angle and oil temperature are displayed by digital instruments.
6 With protect function for over and low voltage and short phase.
7 Save electric power.
8 It can test both distributor ( VE ) and in-line pumps.

PARAMETERS
Output power:7.5/11/15/18.5/22/30KW
Electric supply:3phase 380V/50HZ(or on request)
Interaxe height:125mm
Volume of fuel tank:60L
Cylinders:12cyl.
Feeding fuel pressure  low:0-0.4MPA   high:0-4MPA
Range of speed:(+/-)0-4000RPM
Control fuel temperature:40+/-2
DC. supply:12/24V
Output air:-0.05-0.3MPA
