Hydraulic Bridge Stone Cutter

Hydraulic Bridge Stone Cutter thumbnail-1
Hydraulic Bridge Stone Cutter photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Stone Cutting Machine
Use:
Granite
Place of Origin:
Fujian, China
Contact Supplier Request Quote Chat Now
Fujian Hailong Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
XIAMEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Stone Cutting Machine
Use Granite
Place of Origin Fujian, China
Brand Name HAILONG
Model Number ZDQQ-1600

Specifications

1.marble&granite block cutting machine
2. 1600mm blade diameter
3.cutting 1.4m high block

HYDRAULIC FOUR COLUMNS BRIDGE TYPE CUTTING MACHINE



1.The machine uses the long-span bridge type structure, while both the cross beam and side beam are oil immersed.

2.And the machine can automatic move and adjust the blades. The four columns hydraulic elevation system meets the requirement of both the the stable and fast elevation and the slow march of blades( frequency conversion available according to clients request).

3.The horizontal cutting movements is controlled by the central computer,setting up a special protection facility for the elevation and movement of the side beams.

During the process, the block can be put in the floor directly, saving the cost of the worktable and its maintenance cost.

4.The whole machine is featured with its high precision, stable performance, high production efficience,easy operation and maintenance, particularly suits for the development of international stone's processing.

TECHNOLOGY PARAMENTS

ITEM NO

ZDQQ-1600

 MAX CUTTING LENGTH

30000-3500mm

MAX CUTTING WIDTH

2000mm

MAX CUTTING DEPTH

1400mm

MAX OUTPUT HEIGHT

630mm

MAX BLADE DIAMETER

1600mm

THE DIAMETER OF HORIZONTAL

 CUTTER

400-600mm

MAIN MOTOR POWER

75-90

THE MOTOR POWER OF

HORIZONTAL CUTTIER

15

THE MOTOR POWE OF CROSSING MOVEMENT

22

OVERALL DIMENSION

6628x5500x5935mm





























REMARKS:

Packing:

Sea worthy packaging, fully wrapped with waterproof membrane and air bubbles

Three units in one 20’ GP container

Delivery time :15-45 days from production and 1-2weeks from stock

Guaranty time for elements: half an year

Payment: 30% by T/T in advance as deposit, 70% upon dispatch

Market share:

Fujian Hailong brand granite automatic polishing machine, with our unique advantage have already occupied the domestic and overseas market successfully. Out china market includes the Guangdong province, Guangxi province, Shandong province, Hubei and Hunan province, Hebei province, Sichuan province, Xinjiang province and Hangzhou province with office in each place. And we also extend our overseas market in like Iran, Turkey, Pakistan, India, Indonesia, Vitemn, Thailand.

Company production ability:

We produce more than 60 sets of infrared cutting machine each month.

Service:

Fujian hailong Co., ltd will offer you the best and professional technology and after sales service. Our company builds up a professional group to track all the sold machine for its regular working and maintaining. Besides, we will have half and year guarantee.





 FUJIAN HAILONG MACHINERY CO.,LTD



CRTIFICATE AND PRODUCTION CAPABILITY



1) -ISO 9001:2000,EWC,CE, ITS, Production Assessment, Gold Supplier certificated

2) -Monthly Production Capacity -- 60 sets of half automatic polishing machine, 35sets of automatci polishing machine; 50sets of infrared cutting machine and bridge type cutting machine

3) -Honourable Reputation: CHINA STONE MACHINE TOP 10 ENTERPRISE ; FUJIAN FAMOUS BRAND ENTERPRISE; THE MOST POTENTIAL ENTERPRISE OF CHINA STONE MACHINE;machine; CHINA STONE MACHINE TOP 10 POTENTIAL ENTERPRISE

4) Prompt Reply Within 12 Hours

5) -40 000 square meters work enviornment
