AC750 11ac 750Mbps 2.4Ghz & 5Ghz Dual Band WiFi Repeater /WiFi Extender / Access Point / Wireless Router

AC750 11ac 750Mbps 2.4Ghz & 5Ghz Dual Band WiFi Repeater /WiFi Extender / Access Point / Wireless Router thumbnail-1
AC750 11ac 750Mbps 2.4Ghz & 5Ghz Dual Band WiFi Repeater /WiFi Extender / Access Point / Wireless Router thumbnail-2
AC750 11ac 750Mbps 2.4Ghz & 5Ghz Dual Band WiFi Repeater /WiFi Extender / Access Point / Wireless Router thumbnail-3
AC750 11ac 750Mbps 2.4Ghz & 5Ghz Dual Band WiFi Repeater /WiFi Extender / Access Point / Wireless Router thumbnail-4
AC750 11ac 750Mbps 2.4Ghz & 5Ghz Dual Band WiFi Repeater /WiFi Extender / Access Point / Wireless Router thumbnail-5
AC750 11ac 750Mbps 2.4Ghz & 5Ghz Dual Band WiFi Repeater /WiFi Extender / Access Point / Wireless Router thumbnail-6
AC750 11ac 750Mbps 2.4Ghz & 5Ghz Dual Band WiFi Repeater /WiFi Extender / Access Point / Wireless Router photo-1
AC750 11ac 750Mbps 2.4Ghz & 5Ghz Dual Band WiFi Repeater /WiFi Extender / Access Point / Wireless Router photo-2
AC750 11ac 750Mbps 2.4Ghz & 5Ghz Dual Band WiFi Repeater /WiFi Extender / Access Point / Wireless Router photo-3
AC750 11ac 750Mbps 2.4Ghz & 5Ghz Dual Band WiFi Repeater /WiFi Extender / Access Point / Wireless Router photo-4
AC750 11ac 750Mbps 2.4Ghz & 5Ghz Dual Band WiFi Repeater /WiFi Extender / Access Point / Wireless Router photo-5
AC750 11ac 750Mbps 2.4Ghz & 5Ghz Dual Band WiFi Repeater /WiFi Extender / Access Point / Wireless Router photo-6
US$ 16.50 - 18.00 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
samoxmei
Model Number:
SL-W6304A2
Contact Supplier Request Quote Chat Now
Shenzhen Smartlink EC Industrial Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name samoxmei
Model Number SL-W6304A2
Product Description

The AC750 AP/Router is Mainly used for providing free WiFi service in big area such as factory , community , street or etc. The AP/Router can take an existing 2.4GHz or 5GHz wireless signal, repeat and extend it to a longer range where it is too far away for the router or access point to reach. The AP/Router simultaneously supports 2.4G and 5G wireless network connection, and it can supports 2.4G and 5G transmission speeds of up to 733Mbps. It has 3 x Internal Antennas providing even better wireless performance, transmission rates, stability technology automatically avoids channel conflicts using its channel selection feature.

FEATURES:
The next generation of Wi-Fi, leading 802.11ac standard
Complies with IEEE 802.11 ac/a/b/g/n, standards
Improves wireless coverage in all WLAN networks
Simultaneous 5GHz 433Mbps and 2.4GHz 300Mbps connections for 733Mbps of total bandwidth
Dual Band connections for lag-free HD video streaming and gaming
Maximum WLAN security with WPA2, WPA and WEP(128/64)
Provides 1 10/100Mbps Auto-Negotiation Ethernet LAN ports
Provides 1 10/100Mbps Auto-Negotiation Ethernet WAN ports
Easy wireless security encryption at a push of the WPS button
Features a convenient mode switch, enabling you switch to Router, AP/Repeaer mode
Software wizard for simple setup
Compact, wall plug design for convenient placement
3 x Antennas integrated
Hardware
Ports
1 x LAN, 1 x WAN/LAN
Button
1 x Reset, 1 x WPS
LED
1 x LAN, 1 x WAN/LAN,1 x WPS/Power 1 x WiFi
Chipset
RTL8881AN+8192ER
Flash
32Mbps
SDRAM
512Mbps
Power Supply
Internal DC5V / 1A
Power Plug
UK/EU/US/China/Australia (option)
Power Consumption
2.5W
Rated Voltage/ requency /current
100-240 Va.c. 50/60Hz, 0.1A Max , CLASSⅡ
Wireless
Standard
IEEE802.11ac,IEEE 802.11a, IEEE 802.11b,IEEE 802.11g,IEEE 802.11n
Modulation
11ac: 16QAM, 64QAM 128QAM 256QAM with OFDM
11gn: BPSK, QPSK, 16QAM, 64QAM, OFDM
11b: DQPSK, DBPSK, DSSS, CCK
Speed
802.11ac: up to 433Mbps
802.11n: up to 300Mbps
802.11a: up to 54Mbps
802.11g: 54 M
802.11b: 11 M
Frequency band
5GHz
2.4GHz
Power
802.11b: 17dBm ± 2 dBm 802.11g: 14dBm ± 2 dBm
802.11n: 14dBm ± 2 dBm 802.11ac: 12dBm ± 2 dBm
Distance
Outdoors 300m,
Indoor 100m(According to the actual environment change)
Safety
64/128-bit WEP, AES,TKIP,WPA,WPA2,802.1x,WPA-PSK,WPA2-PSK,MAC , WDS
Requirements
110 ~ 230-volt socket
The WLAN client must support at least the WPA encryption standard.
WLAN access point and the WLAN client with automatic IP address assignment (DHCP)
Forwarding of IPv4-based protocols/Address Resolution Protocol
The network name (SSID) of the WLAN access point must be set to "visible"
