Specifications
Sand Making Machine for Aluminum1.Rock-on-rock
2.Integrated function
3.Hydraulic system
4.Energy saving
High Efficiency Sand Making Machine for
Sand Making Machine
Sand Making Machine for Aluminum is of high-power and low-consumption, which is designed depending on several years hard work and study of mechanical mining equipment. Sand Maker absorbed the advanced technology of the same products of Barmac Company of America, now is of the international level. Sand Making Machine for Aluminum plays an important role in crushing minerals into pieces. Sand Making Machine for Aluminum is widely used in all kinds of mineral, cement, corhart, bauxite chmotte, carborundum grain, glass raw material, machine made construction sand, stone stock and all kinds of metallurgy slag, especially carborundum, sintered bauxite, magnesite, and so on material with features of very hard and anticorrosion. And Sand Making Machine for Aluminum is more productive than other kind of crushers.
Working Principle Of Sand Maker
Stone less than 50mm enters this machine though conveyor belt. Stone is crushed by hitting other stones. Material falls down to impellor cavity. Under great centrifugal force, it hits material that coming downwards. After hitting each other, they force a vortex between impellor and shell, and hit each other several times, finally smaller stone comes out, and goes to vibrating screen. Satisfactory material is transported to sand washing machine, however overlarge material will go back to sand maker to be recrushed. Output sizes can be made according to customers requirement. If input size is larger than the designed size, other crushing equipment will be necessary.
Characteristics of Sand Maker
Simple structure and low operating cost; High efficiency and low consumption; Sand Making Machine for Aluminum has the function of fine crush and crude grinding; Slightly influenced by the moisture content of material, and the max moisture content is 8%; More suitable for crushing mid-hardness and high-hardness materials; Cubic shape of final products, high density of piling up and low iron pollution; More wearable and easy maintenance; Low working noise and light dust pollution.
| Type | 5X7615 | 5X8522 | 5X9532 | 5X1145 | |
| Capacity(t/h) | feed at center&side | 150-280 | 240-380 | 350-540 | 500-640 |
| feed at center | 70-140 | 120-200 | 180-280 | 250-360 | |
|
suitable input size (mm) |
soft material | 35 | 40 | 45 | 50 |
| hard material | 30 | 35 | 40 | 45 | |
| Speed(r/m) | 1700-1900 | 1500-1700 | 1300-1510 | 1100-1310 | |
| Double motor power(kw) | 110-150 | 180-220 | 260-320 | 400-440 | |
| Overall size(mm) | 4100*2330*2300 | 4140*2500*2700 | 4560*2600*2900 | 5100*2790*3320 | |
| Weight(t) | 12.1 | 14.8 | 18.6 | 27.5 | |
| Voltage | 380V, 50Hz | ||||
| Lubrication system | double oil pump motor power | 2*0.31 KW | |||
| safety protection | complementary double pump oil,no oil flow automatic shutdown, water cooling, winter heating motor startup | ||||
| tank heating power | 2KW | ||||
| overall size | 820*520*1270 mm | ||||
