CMC LTCMTS100B Outdoor Docsis 3.0 / C-DOCSIS CMTS WithCATV receiver module
Overview
LTCMTS100B Series D-node CMTS with optical receiver modules. EPON and ONU modules are optional. It supports integrated or distributed CMC module; It supports layer 3 routing functions, and they are suitable for all kinds of IP network; It supports static routing and strategy routing, L2VPN, ARP, and DHCP relay and IPV6; Built-in DHCP/TOD/TFTP server, standardized QoS ensure that quality assurance of different types business have and safety guarantee; It supports the BPI +, CM isolation DOS virus attacks, user isolation and IP address trace.
Specification
Model |
LTCMTS100B(With CATV Optical Receiver Integrated) |
Picture |
|
Standard |
DOCSIS/Euro-DOCSIS 2.0/3.0 C-DOCSIS |
Operating Frequency |
Uplink:5-65MHz,Downlink:108MHz-1002MHz |
Bandwidth(max) |
Downstream:1100Mbps( Single Channel, 8MHz, 64/256/1024QAM ) Upstream:160Mbps( Single Channel, 6.4MHz, QPSK/16/32/64/256QAM ) |
Work Channel |
Downstream:16(max);Upstream:4(max) |
Modulation Mode |
ATDMA/TDMA/SCDMA |
CM Amount |
> 400 |
Case |
Case:Outdoor,Aluminium Protection:IP65 Thunder Proof:6KV,20KA |
Network Port |
GE/10GEPON/GPON |
User Port |
RF Port:1-4 |
Module |
Built-in ONU Module,CATV Optical Receiver Module |
Management |
Telnet,SNMP V1/V2/V3,WEB,CLI. |
Power Consumption |
<65W |
Power |
60V AC/220V AC |
Dimension |
321×215×139(L*W*H) |
Operation Circumstance |
Operating Temperature:-40℃~+65℃ Storage Temperature:-30℃~+70℃ |
