Steel Self Dumping Hoppers
US$ 100 - 500
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
WONTONNE
Model Number:
D Series Self Dumping
Type:
Refuse Collector
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
WONTONNE
Model Number
D Series Self Dumping
Type
Refuse Collector
Steel Self Dumping Hoppers
Product Description
1.Features:
Easy-to-use positive locking machanism.
Safety chain secures hopper to handling vehicle.
Welded seams prevent leakage.
Extra-deep fork openings.
2” formed top lips.
High visibilty blue enamel finish
A wide range of items available for choosing
Customized Dimension and color
2.Options:
4 Lifting lugs
Rubber/cast iron wheel
Surface treatment: painted or galvanized finish.
Steel Self Dumping Hoppers with 4 lugs:
3.Various of specifications for choosing: please contact with our sales!
| CNB Model |
Capacity (kg) |
Volume (m³) | Width (mm) | Depth (mm) | Height (mm) |
Fork Centers |
Net Weight (kg) |
| D-25-LD | 1000 | 0.2 | 514 | 1320 | 966 | 457 | 163 |
| D-33-LD | 1000 | 0.25 | 590 | 1320 | 965 | 457 | 165 |
| D-50-LD | 1000 | 0.4 | 844 | 1320 | 965 | 457 | 175 |
| D-75-LD | 1000 | 0.6 | 793 | 1549 | 1092 | 457 | 190 |
| D-100-LD | 1000 | 0.75 | 41047 | 1549 | 1085 | 457 | 237 |
| D-150-LD | 1000 | 1.2 | 1098 | 1549 | 1320 | 711 | 272 |
| D-200-LD | 1000 | 1.5 | 1428 | 1549 | 1333 | 711 | 291 |
| D-250-LD | 1000 | 2 | 1758 | 1549 | 1320 | 711 | 313 |
| D-300-LD | 1000 | 2.3 | 2068 | 1549 | 1295 | 711 | 385 |
| D-25-MD | 1500 | 0.2 | 514 | 1320 | 966 | 457 | 174 |
| D-33-MD | 1500 | 0.25 | 590 | 1320 | 965 | 457 | 177 |
| D-50-MD | 1500 | 0.4 | 844 | 1320 | 965 | 457 | 190 |
| D-75-MD | 1500 | 0.6 | 793 | 1549 | 1092 | 457 | 238 |
| D-100-MD | 1500 | 0.75 | 41047 | 1549 | 1085 | 457 | 256 |
| D-150-MD | 1500 | 1.2 | 1098 | 1549 | 1320 | 711 | 304 |
| D-200-MD | 1500 | 1.5 | 1428 | 1549 | 1333 | 711 | 331 |
| D-250-MD | 1500 | 2 | 1758 | 1549 | 1320 | 711 | 360 |
| D-300-MD | 1500 | 2.3 | 2068 | 1549 | 1295 | 711 | 415 |
| D-25-HD | 2500 | 0.2 | 514 | 1320 | 966 | 457 | 186 |
| D-33-HD | 2500 | 0.25 | 590 | 1320 | 965 | 457 | 190 |
| D-50-HD | 2500 | 0.4 | 844 | 1320 | 965 | 457 | 206 |
| D-75-HD | 2500 | 0.6 | 793 | 1549 | 1092 | 457 | 261 |
| D-100-HD | 2500 | 0.75 | 41047 | 1549 | 1085 | 457 | 281 |
| D-150-HD | 2500 | 1.2 | 1098 | 1549 | 1320 | 711 | 338 |
| D-200-HD | 2500 | 1.5 | 1428 | 1549 | 1333 | 711 | 372 |
| D-250-HD | 2500 | 2 | 1758 | 1549 | 1320 | 711 | 403 |
| D-300-HD | 2500 | 2.3 | 2068 | 1549 | 1295 | 711 | 442 |
| D-350-HD | 2500 | 2.7 | 2336 | 1752 | 1320 | 711 | 500 |
Packaging & Shipping
Steel self dumping hoppers packed with plywood pallet.
Our Advantages
1.Good quality raw material,advanced production equipments,better performance!
2.Around 6 years development, more experienced and professional!
3.Own factory,more competitive price!
4.Keep inventory of standard products, shorten delivery time!
5.Custom design accepted, wider range of choice!
6.Local distributors in some areas, and developing continuously,easier and in time after-sales service!
