plastic high precision medical tube making machine
- 10 Set / Sets per Month
- Shenzhen or Hongkong
- T/T L/C D/P D/A Credit Card PayPal
Product Details
| Condition: | New | Application: | Pipe | Plastic Processed: | Other, pvc/pe/pu |
| Screw Design: | Single-screw | Automatic Grade: | auto | Place of Origin: | Guangdong, China |
| Brand Name: | SongHu | Model Number: | SHSY45 | Voltage: | 380V |
| Power(W): | 15KW | Dimension(L*W*H): | 12x1.5x1.8m | Weight: | 1.5ton |
| Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
1. Usage:Precision medical tube extrusion line is mainly used in the production of oxygen tube, blood transfusion tube, catheter, drainage tube, tracheal intubation, central venous catheter, anesthesia tube, perforated tube and various types of precision medical tubes.
2.Applicable Material: PVC,PU
3. Machine includes:
Model | Equipment | Quality |
1 | 45mm main extruder | 1SET |
2 | Precise mould | 1SET |
3 | 4meters water calibration tank | 1SET |
4 | Servo pulling and cutting | 1SET |
5 | Auto conveying and collecting systems | 1SET |
4.Main technical parameter:
Model
| Screw Dia. | Screw L/D | Motor power | Haul-off power | Cutter power | Capacity(kgs/hr.) |
SHSY-45 | 45 | 25-30 | 11kw | 1.5 | 1.5 | 15-20 |
5. Production field
The machine work site conditions.
Precision extruder is outing products and senting it to the vacuum calibration cooling tank system to cool.
6. Samples how
Nasal oxygen cannula.
The size of infusion tube is different.
There are the different kinds of infusion tube.
Common type of infusion tube
Our certificate:
