Help CenterREOO China EVA FILM for Manufacturing Solar Panel
Related Products
-
REOO Solar Panel Raw Material and Solar Cell and PV Junction Box Supplier's ChoiceUS$ 5,000 - 6,500MOQ: 1 Set -
Hot Selling Photovoltaic Solar Panel High Quality EVA FilmUS$ 1.38 - 1.42MOQ: 10 Square Meters
-
Aluminum Frame for Soalr PanelUS$ 9.8 - 9.85MOQ: 100 Sets
-
REOO 156 x 156mm Poly Crystalline Silicon Solar Cell for Solar Panel Raw MaterialUS$ 0.48 - 1MOQ: 50 Watts
-
REOO Solar Panel Raw Material Soldering Ribbon, Tabbing WireUS$ 16 - 17MOQ: 1 Kilogram
Whole Set Solar Panel Manufacturing Equipment with Raw
Materials
JCC EVA Solar cell encapsulation film model:
Fast Cure:JCC-105; High penetration type:JCC-105 -T
product specification :
1,Lamp shape:EVA Ultra Barrier Solar Films are Double stripe type;and also
can manufacture products of other stripes according to customers’ needs.
2,Product thickness:We can supply different thickness arranging from
0.30-0.80mm, the thickness of conventional product are 0.40mm and 0.50mm,
thickness tolerance:±0.03mm.
3,Product width: any width below 2000mm, and the normal width: 350,550,
680,810,820,980,1000mm, width tolerance: ±3mm
4,Length of each roll:100m,Tolerance:±1 m can manufacture according
to customers’ needs
Curing process conditions:
JCC-105/ JCC-105-T Suggested laminating temperature:140±2℃(can
change according to customers’ needs)
pumpdown time 4-6min
Laminated time 8-10min
Technological conditions :
To ensure the quality of modular package, we suggest that after the
calibration of laminating machine temperature, following the technological
conditions can ensure EVA film crosslinking degree is above 80% and then
ensure the quality.If you want to increase the degree of crosslinking layer , you can
be appropriately raise the temperature or pressure holding time
1, JCC-105/JCC-105-T:
Laminating machine temperature 138-142℃,vacuumize 5min,forcing
60s,Laminated keep 8-10min.
2,Laminating instructions:
(a),Laminating conditions according to the performance of the laminating
machine. According to the temperature characteristics of each
laminating machine,tracking test must at any time,Selection of
crosslinking degree between 70% ~ 70% after curing of process
conditions is preferred.Crosslinking degree is too low or too high can
lead to poor late aging performance.
(b),If laminating machine working environment temperature is different,
process conditions should be adjusted, specific to each laminating
machine parameters shall prevail.
3, After the completion of the laminated,Should after the temperature of
laminated good components down natural 80 ℃ and then Then open
the warm cloth , remove the components to trimming and deflashing .
Installation
We send engineer or technicians to buyers factory to install machine.
All expenditure on travel, food, accommodation and transportation of our engineers/ technicians for installation will be borne by buyer.
REOO company borne the salary of engineer.
Training
We supply both overseas and local training to the engineers and technicians on operation and maintenance.
buyer borne air tickets, lodging, food and training material .
Minimum 12 (twelve) months warranty of all products and services .
guarantee for the spares and required maintenance or replacement support are to be provided . Buyer borne the cost of the material for parts of maintenance.
Backup spares:
We supply essential backup spares. items beyond warranty periods, buyer borne the cost.
Why buy solar panel production line from REOO technology ?
We have more experience for design, manufacturing, packing, shipping, installation, training, trial production in all of world.
We have more than 10 years experience for manufacture and export solar panel machines
Our engineer can install all of machines for making solar panel.
Our engineer can supply best technology.
We can train for all of machines.
We supply all tools and accessories for production, It is difficult be purchased in other countries. and these tools is free, Do not need money.
We can supply all of raw material for manufacture solar panel in good quality and lower price.
Please look the video from by REOO solar.
We can supply technical documents for apply TUV certificated. It is free.
|
