REOO 156 x 156mm Poly crystalline silicon solar cell for solar panel raw material
- 300000 Watt / Watts per Month
- Shanghai
- T/T
You May Like
-
REOO Solar panel raw material soldering ribbon, tabbing wire
-
REOO EVA film for solar cell encapsulation
Quality Choice
-
REOO solar and PV back sheet supply for the solar module
-
High quality solar panel backsheet used for solar panel production
-
Low iron tempered glass for solar panel 3.2mm/4mm
Supplier's Choice
-
High quality silicon gel for solar panel
Product Details
| Place of Origin | Jiangsu, China | Brand Name | REOO | |
| Model Number | 156*156mm | Type | Other, solar cell |
Product Description
156*156mm Polycrystalline silicon solar cell
Model | Efficiency | Power | Max power current | Max power voltage | Short Circuit Current | Open Circuit Voltage | Fill Factor |
Eff (%) | Ppm(w) | Ipm(A) | Vpm(V) | Isc(A) | Voc(V) | FF(W) | |
SPSM156M-S1 | ≥16.9% | 4.13 | 7.597 | 0.519 | 8.463 | 0.623 | 78.29 |
SPSM156M-S2 | 16.70%-16.89% | 4.08 | 7.886 | 0.518 | 8.412 | 0.622 | 78.06 |
SPSM156M-H1 | 16.50%-16.89% | 4.03 | 7.793 | 0.517 | 8.382 | 0.622 | 77.30 |
SPSM156M-H2 | 16.30%-16.49% | 3.99 | 7.741 | 0.515 | 8.329 | 0.622 | 76.96 |
SPSM156M-H3 | 16.10%-16.29% | 3.94 | 7.697 | 0.512 | 8.279 | 0.620 | 76.77 |
SPSM156M-M1 | 15.90%-16.09% | 3.89 | 7.648 | 0.509 | 8.225 | 0.618 | 76.63 |
SPSM156M-M2 | 15.70%-15.89% | 3.85 | 7.600 | 0.506 | 8.172 | 0.616 | 76.48 |
SPSM156M-M3 | 15.50%15.69% | 3.80 | 7.553 | 0.503 | 8.123 | 0.613 | 76.24 |
SPSM156M-M4 | 15.30%-15.49% | 3.75 | 7.499 | 0.500 | 8.074 | 0.611 | 76.02 |
SPSM156M-M5 | 15.10%-15.29% | 3.70 | 7.441 | 0.498 | 8.035 | 0.609 | 75.65 |
SPSM156M-O1 | 14.90%-15.09% | 3.65 | 7.393 | 0.495 | 8.021 | 0.607 | 74.99 |
SPSM156M-O2 | 14.70%-14.89% | 3.60 | 7.327 | 0.492 | 8.010 | 0.607 | 74.13 |
SPSM156M-O3 | 14.50%-14.69% | 3.55 | 7.265 | 0.489 | 7.979 | 0.606 | 73.47 |
SPSM156M-O4 | 14.0%-14.49% | 3.48 | 7.190 | 0.484 | 7.934 | 0.605 | 72.50 |
SPSM156M-D | ≤14.0% | 2.40 | 5.562 | 0.430 | 7.581 | 0.572 | 55.10 |
IM156 Product Polycrystalline silicon solar cell
Dimension 156mm*156mm ±0.5mm
Thickness(Si) 220μm±20μm
Front Blue silicon nitride antireflection coatings 1.8mm silver busbar
Back Full-surface aluminum back -surface field 4.5mm (silver aluminum ) continuous soldering pads
Dimension 156mm*156mm ±0.5mm
Front Blue silicon nitride antireflection coatings 1.6mm silver busbar
Back Full-surface aluminum back -surface field 2.5mm (silver aluminum ) continuous soldering pads
Installation
We send engineer or technicians to buyers factory to install machine.
All expenditure on travel, food, accommodation and transportation of our engineers/ technicians for installation will be borne by buyer.
REOO company borne the salary of engineer.
Training
We supply both overseas and local training to the engineers and technicians on operation and maintenance.
buyer borne air tickets, lodging, food and training material .
Minimum 12 (twelve) months warranty of all products and services .
guarantee for the spares and required maintenance or replacement support are to be provided . Buyer borne the cost of the material for parts of maintenance.
Backup spares:
We supply essential backup spares. items beyond warranty periods, buyer borne the cost.
Why buy solar panel production line from REOO technology ?
We have more experience for design, manufacturing, packing, shipping, installation, training, trial production in all of world.
We have more than 10 years experience for manufacture and export solar panel machines
Our engineer can install all of machines for making solar panel.
Our engineer can supply best technology.
We can train for all of machines.
We supply all tools and accessories for production, It is difficult be purchased in other countries. and these tools is free, Do not need money.
We can supply all of raw material for manufacture solar panel in good quality and lower price.
Please look the video from by REOO solar.
We can supply technical documents for apply TUV certificated. It is free.
