2014 new design single heating zone vacuum chamber furnace
Featrues of vacuum chamber furnace
1.Alarm system, can protect the system from over temperature.
3.Programmable and PID automatic control
4.Metal key or touch panel operating interface for your option
5.Imported energy saving chamber material
6. Manual, automatic switch freely, easy to operate
7.High sealed steel tank
Technical parmaters of vacuum chamber furnace
| Model | CY-V1700-15L |
| Limiting temperature | 1700℃ |
| Working temperature | ≤1650℃ |
| Heating rate | 1~20℃/min(adjustable) |
| Temperature zone | Single |
| Temperature accuracy | ±1℃ |
| Chamber size | 300*250*200mm |
| Heating element | MoSi2 rod |
| Thermal couple | B Type |
| Temperature control | PID automatic control via SCR power control |
| Heating curves | 51 steps programmable |
| Chamber material | Imported fiber |
| Sealed method | steel tank |
| Main power | 9.5kw |
| Working voltage | 220V 50-60Hz |
| Standard accessories | protective gloves 1 pair, crucible furnace hook 1 pc, crucible 5pcs, manual book |
Pictures show of vacuum chamber furnace
Packaging of vacuum chamber furnace
PLY WOOD BOX as below picture show. or as customer request.
Shipping and transportation
As customer request. Generally, Our mode of transport are as by sea, by air or rail transport
Payment
T/T, L/C, WEST UNION, PAYPAL, ESCROW AND ETC
Warranty
Main product is 12month, except wearing parts.
Wearing parts as below:
Quartz tube, vacuum flange, tube blockage, O-ring, protective gloves, crucible furnace hook, PTFE tube, stainless steel fittings, stainless steel bellows, adapter, hex wrench
Factory show
Zhengzhou CY Scientific Instrument Co., Ltd is mainly engaged in the research and development, design, manufacturing and sales of equipment used in scientific researches. Independence and innovation is the company's tenet.
