Customized Bridgman Crystal Growing System Furnace for Metal Single Crystal from 1200 - 1700ºC - EQ-SKJ-BG
Bridgman Crystal Growing System Furnace
Introduction of Bridgman Crystal Growing System Furnace
CY designs and manufacture various compact Bridgman crystal growth furnace based on customer's requirement to grow
metallic and semiconductor single crystal for researchers
Bridgman Crystal Growing System Furnace
Specification of Bridgman Crystal Growing System Furnace
Max, Working Temperature Range | 1200°C 1500oC 1700°C Please tell us max. working temperature when asking a quote |
Thermal gradient | Two Zone or Three Zone Heating |
Travel Distance | 200 - 300 mm |
Travel Speed ( The lowest ) | > = 1.0 mm/ hr |
Rotation Speed | 0 - 30 RPM |
Vacuum Level | 10 E-5 Torr by Turbo pump |
Control Interface | PC |
Crucible | Graphite |
Crystal Grown | Al,Ag, Au, Cu, Mg, Ni -----
|
Photos of Bridgman Crystal Growing System Furnace
Zhengzhou CY Scientific Instrument Co., Ltd is mainly engaged in the research and development, design, manufacturing andsales of equipment used in scientific researches. Independence and innovation is the company's tenet.Our main products
include: tube furnace, muffle furnace, plasma cleaner, vacuum furnace, atmosphere furnace,CVD system and customized
lab equipment.Welcome you come to visit us.
