CE certified double way graphene preparation equipment
Featrues of graphene preparation equipment
1.Upper and lower sub-structure, easy to pick and place tubes
2.High purity quartz tube, resistance high temperature 1200 ℃
3.Programmable and PID automatic control
4.Metal key or touch panel operating interface for your option
5.Imported energy saving chamber material
6. Furnace using double liner structure, the middle has gap isolation, even if the furnace temperature up to 1000 Chang, furnace surface remains safe to touch
7. Furnace is equipped with an output voltage and output current detection table, can see the real time heated condition
Technical parmaters of graphene preparation equipment
| Model | CY-O1200-80-2ZV10 |
| Display | LED |
| Chamber material | imported fiber |
| Heating element | imported alloy heating wire |
| Max.temperature | 1200℃ |
| Working temperature | ≤1150℃ |
| Heating rate | ≤20℃(suggestion:10℃/min) |
| Heating zone | Single |
| Temperature zone length | 420mm |
| Thermostatic zone length | 200mm |
| Tube Material | high purity quartz |
| Tube Size | 80mm |
| Tube length | 1400mm |
| Sealed method | stainless steel vacuum flange |
| Tightness | 4.03*10-³Pa |
| Control mode | PID automatic control via SCR power control |
| Temperature accuracy | ±1℃ |
| Current monitoring | yes |
| Voltage monitoring | yes |
| Over temperature alarm | yes |
| Over current protection | yes |
| Thermal couple | K type |
| Certification | CE |
| Power supply | AC 220V 50-60Hz |
| Main power | 4.5kw |
| Gas channel | 3 gas way |
| Flowmeter | proton flowmeter |
| Gas pressure | -0.1-0.15Mpa |
| Vacuum degree | 5-10Pa |
| Pump connection | KF16Bellows, KF16 clamps, KF16 flapper valve |
| Accessories | quartz tube, vacuum flange,tube blockage,O-ring, glove,Crucible furnace hook, PTFE tube, stainless steel fittings, stainless steel bellows, adapter, 5mm hex wrench,manual book |
Pictures show of graphene preparation equipment
Packaging of graphene preparation equipment
PLY WOOD BOX as below picture show. or as customer request.
Shipping and transportation
As customer request. Generally, Our mode of transport are as by sea, by air or rail transport
Payment
T/T, L/C, WEST UNION, PAYPAL, ESCROW AND ETC
Warranty
Main product is 12month, except wearing parts.
Wearing parts as below:
Quartz tube, vacuum flange, tube blockage, O-ring, protective gloves, crucible furnace hook, PTFE tube, stainless steel fittings, stainless steel bellows, adapter, 5mmhex wrench
Factory show
Zhengzhou CY Scientific Instrument Co., Ltd is mainly engaged in the research and development, design, manufacturing and sales of equipment used in scientific researches. Independence and innovation is the company's tenet.
