Hot aluminum frame dimmable recessed led pannel light 9w
Features of Hot aluminum frame dimmable recessed led pannel light 9w
Polyamide body with latest heat disspation technology; Opal acrylic diffuser,even light output; High efficiency
SMD LED Chips, built-in trailing edge dimmable driver; Hot aluminum frame dimmable recessed led pannel light 9w
Extended Life Time:3 years warranty
Avantages of Hot aluminum frame dimmable recessed led pannel light 9w
1. Advanced LED lighting distribution process, Hot aluminum frame dimmable recessed led pannel light 9w
2. High quality smd led chipset for the Downlight
3. High-tech heat dissipation for radiatorm
4. Even Lighting: High Intensity / No Halationoule led
5. Major Energy saving: Over 90% Compare to Incandescent
6. Reduces Light Pollution: No wasted Light
7. No Hazardous Emissions: No IR or UV Radiation, Do Not Attract Insects
8 free power driver will be sent with downlight now
Hot aluminum frame dimmable recessed led pannel light 9w
Specifications of Hot aluminum frame dimmable recessed led pannel light 9w
| Type | SP159W | |
| Input voltage &frequency | AC85V-265V 50/60Hz | |
| Light source | SMD2835/45pcs | |
| Power consumption | 9W | |
| Color temperature | WW:2800K~3200K | NW:4000K~4500K |
| LED luminous efficiency | 70lm/W | CW:6000K~6500K |
| Lamp Lumens | 660lm | |
| CRI(Ra) | >80 | |
| Beam angle | 120° | |
| Working temperature | -40°C~60°C | |
| Housing material | Aliminium shell+PC cover | |
| Product size | 150*150mm,cutout:130*130*13mm |
|
| Light source life span | ≥50,000 hrs | |
Other round panel specification:
| Part No. | Input Voltage | Power Factor | LED Chip | LED QTY | Power | Dimension | Cutout size | Lumens |
| SP093W | AC85-265V | >0.8 | SMD2835 | 15 | 3W | 90*90mm | 70x70x13mm | 210lm ± 10%lm |
| SP114W | AC85-265V | >0.8 | SMD2835 | 20 | 4W | 110*110mm | 90x90x13mm | 280lm ± 10%lm |
| SP126W | AC85-265V | >0.8 | SMD2835 | 30 | 6W | 120*120mm | 100x100x13mm | 450lm ± 10%lm |
| SP159W | AC85-265V | >0.9 | SMD2835 | 45 | 9W | 150*150mm | 130x130x13mm | 660lm ± 10%lm |
| SP1712W | AC85-265V | >0.9 | SMD2835 | 60 | 12W | 170*170mm | 150x150x13mm | 840lm ± 10%lm |
| SP2014W | AC85-265V | >0.9 | SMD2835 | 70 | 14W | 200*200mm | 180x180x13mm | 1000lm ± 10%lm |
| SP2218W | AC85-265V | >0.9 | SMD2835 | 90 | 18W | 225*225mm | 195x195x13mm | 1200lm ± 10%lm |
Hot aluminum frame dimmable recessed led pannel light 9w
2. Hotels lighting
3. Conference room lighting
4. Factories, offices lighting
5. Business negotiation venues lighting
6. Housing, institutions and other buildings lighting
7. Schools, hospitals lighting
Install design:
Quality control Hot aluminum frame dimmable recessed led pannel light 9w
100% of the lamps will be tested and keep lighting for 48 hours to test its quality reliability, and we will also test its temperature after 24 hours’ lighting. Then after it is cool we again test 100% of the lamps to see if it still work well. Each lamp should pass all these QC procedures before shipping to customer.
SAA for the whole lamp, IC-F test, C-tick, CE ROHS Hot aluminum frame dimmable recessed led pannel light 9w
Our service Hot aluminum frame dimmable recessed led pannel light 9w
Packing&Shipping of Hot aluminum frame dimmable recessed led pannel light 9w
1.Small order can be acceptted, and we are offerring the fast delivery date, only 3 to 12 work days can be ready for your order.
2. Delivery by air (TNT UPS DHL) or by sea are all available
3.Sample order 1-3d working ays and the bulk order 10-15 working days
Led square ceiling light Packing:
1:Qty/ctn:20pcs
2:Gross Weight:18.5kg
3:Size of carton:55x40x30mm
If your order quantity more than 500pcs, we would like to supply free color box packing
Send Inquiry to This Supplier
