Home > Lights & Lighting > LED Interior Lighting > LED Panel Light > 2014 Hot Sell 3W 4W 6W 8W Led Panel Light SMD Ceiling Lamp

2014 Hot Sell 3W 4W 6W 8W Led Panel Light SMD Ceiling Lamp

2014 Hot Sell 3W 4W 6W 8W Led Panel Light SMD Ceiling Lamp thumbnail-1
2014 Hot Sell 3W 4W 6W 8W Led Panel Light SMD Ceiling Lamp thumbnail-2
2014 Hot Sell 3W 4W 6W 8W Led Panel Light SMD Ceiling Lamp thumbnail-3
2014 Hot Sell 3W 4W 6W 8W Led Panel Light SMD Ceiling Lamp thumbnail-4
2014 Hot Sell 3W 4W 6W 8W Led Panel Light SMD Ceiling Lamp photo-1
2014 Hot Sell 3W 4W 6W 8W Led Panel Light SMD Ceiling Lamp photo-2
2014 Hot Sell 3W 4W 6W 8W Led Panel Light SMD Ceiling Lamp photo-3
2014 Hot Sell 3W 4W 6W 8W Led Panel Light SMD Ceiling Lamp photo-4
US$ 8.5 - 10.5 MOQ: 10 Pieces
Key Specifications
Get Latest Price
LED Light Source:
Epistar
Warranty(Years):
3
Input Voltage(V):
100-240
Contact Supplier Request Quote Chat Now
Dongguan A-One LED Lighting Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source Epistar
Warranty(Years) 3
Input Voltage(V) 100-240
Lamp Power(W) 3
Lamp Luminous Flux(lm) 210
Lamp Luminous Efficiency(lm/w) 70
Color Temperature(CCT) Cool White
Working Temperature(℃) -40, 60
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum Alloy
IP Rating IP44
Certification CE, EMC, LVD, SAA
Place of Origin Guangdong, China
Brand Name A-ONE LED
Model Number RP093W led panel

Specifications

led panel light
1.CE ROHS SAA approved
2.SMD Round LED Panel lamp
3.Good quality & Fast delivery
4.3 years warranty

 2014 hot sell 3W 4W 6W 8W led panel light SMD ceiling lamp





Type RP093W
Input voltage &frequency AC85V-265V 50/60Hz
Light source SMD2835/15pcs
Power consumption 3W
Color temperature WW:2800K~3200K NW:4000K~4500K
LED luminous efficiency  80lm/W  CW:6000K~6500K
Lamp Lumens 210lm
CRI(Ra) >78
Beam angle 120°
Working temperature -40°C~60°C
Housing material Aliminium shell+PC cover
Product size

90*13mm,cutout:70mm
Light source life span ≥50,000 hrs



Round led panel advantage:

1, Simple design, 13mm thickness.

2, Isolated driver, with Phillips IC and Japan Rubycon capacitor.

3, CE, RoHS approved.

4, Dimmable light control available

5, 3 years warranty.

Other round panel specification:



Part No. Input Voltage Power Factor LED Chip LED QTY Power Dimension Cutout size Lumens
RP093W AC85-265V >0.65 SMD2835 15 3W 90*13mm 70mm 210lm ± 10%lm
RP114W AC85-265V >0.65 SMD2835 20 4W 110*13mm 90mm 280lm ± 10%lm
RP126W AC85-265V >0.65 SMD2835 30 6W 120*13mm 100mm 420lm ± 10%lm
RP159W AC85-265V >0.9 SMD2835 45 9W 150*13mm 130mm 630lm ± 10%lm
RP1712W AC85-265V >0.9 SMD2835 60 12W 170*13mm 150mm 840lm ± 10%lm
RP1812W AC85-265V >0.9 SMD2835 60 12W 180*13mm 160mm 840lm ± 10%lm
RP2015W AC85-265V >0.9 SMD2835 75 15W 200*13mm 180mm 1100lm ± 10%lm
RP2218W AC85-265V >0.9 SMD2835 90 18W 225*13mm 200mm 1300lm ± 10%lm
RP2420W AC85-265V >0.9 SMD2835 100 20W 240*13mm 220mm 1500lm ± 10%lm
RP3024W AC85-265V >0.9 SMD2835 120 24W 300*13mm 280mm 1800lm ± 10%lm







International Colour temperature standard:







1. General indoor lighting

2. Hotels lighting

3. Conference room lighting

4. Factories, offices lighting

5. Business negotiation venues lighting

6. Housing, institutions and other buildings lighting

7. Schools, hospitals lighting

8. Places need to energy efficiency and high color developing index

Install design:





Led ceiling light Packing:



1:Qty/ctn:40pcs
2:Gross Weight:23.5kg
3:Size of carton:64x51x29mm





Material  Control:



We will check all outer ring one by one  remove any stain of outer to protect smooth surface;



100% of the lamps will be tested and keep lighting for 48 hours to test its quality reliability , and we will also test its temperature after 24 hours’ lighting.

Then after it is cool we again test 100% of the lamps to see if it still work well . Each lamp should pass all these QC procedures before shipping to customer.





































1. For all your inquires about us or our products,we will reply you in detail within 24 hours


2. We own well-tranied and passional sales & after –sale services who can speak fluent Engligh language


3. We offer OEM services. Can print your own logo on product, can customize the retail box packing and other things.

4. We have very experienced R&D engineers and we have strong ability to do ODM projects.

5.Protection of your sales area, ideas of design and all your private informaton.



6.We make color box free when  QTY more than 1000pcs



7.Our convenient payment and effective transportation  service:





Quality, Promise and Value are the key of our success. If you are looking for a business partner supplying super quality products, welcome to contact A-ONE:
