2014 New Dimmable Hot 4W Led Panel Round White Silver Finish

2014 New Dimmable Hot 4W Led Panel Round White Silver Finish thumbnail-1
2014 New Dimmable Hot 4W Led Panel Round White Silver Finish thumbnail-2
2014 New Dimmable Hot 4W Led Panel Round White Silver Finish thumbnail-3
2014 New Dimmable Hot 4W Led Panel Round White Silver Finish thumbnail-4
2014 New Dimmable Hot 4W Led Panel Round White Silver Finish thumbnail-5
2014 New Dimmable Hot 4W Led Panel Round White Silver Finish photo-1
2014 New Dimmable Hot 4W Led Panel Round White Silver Finish photo-2
2014 New Dimmable Hot 4W Led Panel Round White Silver Finish photo-3
2014 New Dimmable Hot 4W Led Panel Round White Silver Finish photo-4
2014 New Dimmable Hot 4W Led Panel Round White Silver Finish photo-5
US$ 9.5 - 11.5 MOQ: 10 Pieces
Key Specifications
Get Latest Price
LED Light Source:
Epistar
Warranty(Years):
3
Input Voltage(V):
85-265V AC
Contact Supplier Request Quote Chat Now
Dongguan A-One LED Lighting Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHZNEHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source Epistar
Warranty(Years) 3
Input Voltage(V) 85-265V AC
Lamp Power(W) 4
Lamp Luminous Flux(lm) 300lm
Lamp Luminous Efficiency(lm/w) 80
Color Temperature(CCT) Warm White
Working Temperature(℃) -40, 60
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum Alloy
IP Rating IP44
Certification CE, EMC, LVD, SAA
Model Number RP114W hot led panel
Place of Origin Guangdong, China
Brand Name A-ONE LED hot led panel

Specifications

10W COB LED Downlight
1.Isolated constant current led driver
2.high quality CE ROHS SAA
3.fast delivery
4. 3 years warranty



2014 new Dimmable hot 4W led panel round white silver finish CE ROHS SAA





Type RP114W
Input voltage &frequency AC85V-265V 50/60Hz
Light source SMD2835/20pcs
Power consumption 4W
Color temperature WW:2800K~3200K NW:4000K~4500K
LED luminous efficiency  80lm/W  CW:6000K~6500K
Lamp Lumens 300lm
CRI(Ra) >78
Beam angle 120°
Working temperature -40°C~60°C
Housing material Aliminium shell+PC cover
Product size

100*13mm,cutout:90mm
Light source life span ≥50,000 hrs





Other round panel specification:



Part No. Input Voltage Power Factor LED Chip LED QTY Power Dimension Cutout size Lumens
RP093W AC85-265V >0.65 SMD2835 15 3W 90*13mm 70mm 210lm ± 10%lm
RP114W AC85-265V >0.65 SMD2835 20 4W 110*13mm 90mm 300lm ± 10%lm
RP126W AC85-265V >0.65 SMD2835 30 6W 120*13mm 100mm 420lm ± 10%lm
RP159W AC85-265V >0.9 SMD2835 45 9W 150*13mm 130mm 630lm ± 10%lm
RP1712W AC85-265V >0.9 SMD2835 60 12W 170*13mm 150mm 840lm ± 10%lm
RP1812W AC85-265V >0.9 SMD2835 60 12W 180*13mm 160mm 840lm ± 10%lm
RP2015W AC85-265V >0.9 SMD2835 75 15W 200*13mm 180mm 1100lm ± 10%lm
RP2218W AC85-265V >0.9 SMD2835 90 18W 225*13mm 200mm 1300lm ± 10%lm
RP2420W AC85-265V >0.9 SMD2835 100 20W 240*13mm 220mm 1500lm ± 10%lm
RP3024W AC85-265V >0.9 SMD2835 120 24W 300*13mm 280mm 1800lm ± 10%lm











1. General indoor lighting

2. Hotels lighting

3. Conference room lighting

4. Factories, offices lighting

5. Business negotiation venues lighting

6. Housing, institutions and other buildings lighting

7. Schools, hospitals lighting

8. Places need to energy efficiency and high color developing index

Install design:





Led ceiling light Packing:



1:Qty/ctn:40pcs
2:Gross Weight:23.5kg
3:Size of carton:64x50x30mm





Material  Control:



We will check all outer ring one by one  remove any stain of outer to protect smooth surface;



100% of the lamps will be tested and keep lighting for 48 hours to test its quality reliability , and we will also test its temperature after 24 hours’ lighting.

Then after it is cool we again test 100% of the lamps to see if it still work well . Each lamp should pass all these QC procedures before shipping to customer.





































1. For all your inquires about us or our products,we will reply you in detail within 24 hours


2. We own well-tranied and passional sales & after –sale services who can speak fluent Engligh language


3. We offer OEM services. Can print your own logo on product, can customize the retail box packing and other things.

4. We have very experienced R&D engineers and we have strong ability to do ODM projects.



5.Protection of your sales area, ideas of design and all your private informaton.



6.We make color box free when  QTY more than 1000pcs



7.Our convenient payment and effective transportation  service:





Quality, Promise and Value are the key of our success. If you are looking for a business partner supplying super quality products, welcome to contact A-ONE:
