1200c High Temperature PID Control Crucible Melting Furnace

Name: 1200c High Temperature PID Control Crucible Melting Furnace
Brand: CYKY
SKU: 112041895
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

CYKY

Model Number:

CY-1200CF

Place of Origin:

Henan, China

Zhengzhou CY Scientific Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Zhengzhou QingdaoTianjin Beijing Ningbo etc.

Delivery Detail:

Delivery time depends on order quantity.

Brand Name CYKY

Model Number CY-1200CF

Place of Origin Henan, China

1200c high temperature PID control crucible melting furnace

Product Description

Featrues of crucible melting furnace

1. Side door, easy to operate
2. high quality alumina fiber, resistance high temperature 1200 ℃
3. Programmable 30 setps and PID automatic control

4. Double and round furnace structure, furnace temperature field uniformity

5. PC interface control

6. Chamber with crucible, easy to operate

Technical parameters of crucible melting furnace

Furnace Structure & Chamber	Double Layer steel structure with air cooling High purity fiber alumina insulation ( made in Japan factory) for max.energy saving Heating chamber size: Ø9.5" x 8.6"H , 9 liter capacity Hinged type cover for easy sample loading All accessories are included for immediate use One pcs refractory disk, which can be put on bottom of furnace to protect furnace liner from wearing out. Three pcs refractory supports, which may be put on top of the disk and bottom of the crucible to adjusting crucible height.
Power	3.5KW Max.
Voltage	AC 208 ~ 240V Single Phase 50/60Hz
Max. Temperature	Max. 1250 °C for short time < 1hour Continuous working temperature: < 1200°C
Max. Heating Rate	40 °C /min
Temperature controller	PID automatic control and auto-tune function. 30 programmable segments for precise process Built in protection for over-heated and broken Thermal couple.
Temperature Accuracy	+/- 1 °C
Heating Element	1300oC grade Fe-Cr-Al Alloy doped by Mo
Dimension	510 x 435 x 425mm
Net Weight	30 Kg
Shipping package size after crating	45" x28" x 35"
Shipping weight	260 Lbs
Warranty	One year limited warranty
Certificate	CE Certified
