lab crucible furnace /high temperature crucible furnace for sale
Application of crucible furnace
Crucible furnace is mainly used in colleges and universities, scientific research, industrial and mining enterprises for high temperature sintering, metal annealing, quality inspection and etc
Featrues of crucible furnace
1. Side door, easy to operate
2. high quality alumina fiber, resistance high temperature 1200 ℃
3. Programmable 30 setps and PID automatic control
4. Double and round furnace structure, furnace temperature field uniformity
5. PC interface control
6. Chamber with crucible, easy to operate
Technical parmaters of crucible furnace
| Model | CY-1200CF |
| Max.temperature | 1200℃ |
| Working temperature | 1100°C |
| Heating element | Imported alloy wire |
| Thermal couple | K type |
| Temperature control | PID automatic control via SCR power control |
| Chamber size | 200*200*210mm |
| Heating rate | 0-15℃/min (suggestion≤10℃) |
| Temperature accuracy | ±2℃ |
| Rated power | AC 220V, single phase, 50Hz |
| Outside dimension | 580*470*670mm |
| Gross weight | 80kg |
| Packing | PLY wood box |
Pictures show of crucible furnace
Packaging of crucible furnace
PLY WOOD BOX as below picture show. or as customer request.
Shipping and transportation
As customer request. Generally, Our mode of transport are as by sea, by air or rail transport
Payment
T/T, L/C, WEST UNION, PAYPAL, ESCROW AND ETC
Warranty
Main product is 15 month, except wearing parts.
Factory show
Zhengzhou CY Scientific Instrument Co., Ltd is mainly engaged in the research and development, design, manufacturing and sales of equipment used in scientific researches. Independence and innovation is the company's tenet.
