Automatic Car Wash Foam Machine With Foam and Wax Systems

Name: Automatic Car Wash Foam Machine With Foam and Wax Systems
Brand: Youda
SKU: 112041801
Availability: InStock

US$ 16,000 - 20,500 MOQ: 1 Set

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Youda

Model Number:

DA-W300ST

Yancheng Youda Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Youda

Model Number DA-W300ST

Size W3600 x H2850 x L2460mm

Material Steel hot galavanzing

Automatic car wash foam machine with foam and wax systems

CE Approved

DA-W300ST Automatic car washing machine is equipped with new-generation car model detection

technology which is featured as combination of various ways of car washing and fast speed of

cleaning, the profiling air-dry technology ensures the efficient drying; the combination of various ways

of washing improves the washing speed; the hot-dip galvanized frame ensures a longer service time.

Main Futures:

1. Professional washes for cars, jeeps and all kinds of coaches below 9 seats;

2. Adopting advanced technology and full module design, this can be combined to more than ten different functions for different needs;

3. The main electrical components are imported from famous foreign factory, which can ensure safe and reliable;

4. Unique fault self-testing system; Waterproof motor; profiling powerful air-dry system

5. Adopting the advanced high pressure system; Pre- swing high pressure water wash does not hurt the car;

6. Hot-dip galvanizing (Zinc layer>70um) frame;

7. Maintenance-free of polymer materials roller and TN lifting mechanism;

8. Japanese EVA brushes to prevent injury car;

Technical Data:

Item	Model	DA-W300ST-1	DA-W300ST-2	DA-W300ST-3
Size	Machine size	W3600 x H2850 x L2460mm
	Rail size	W3200 x L8150mm
	Swing arm size	H2850mm
	Washable car size	W2150 x H2200 x L5350mm
Installation	Assembling range	W3650 x L9800mm
	Air supply	Pressure 0.6-0.8Mpa
	Total electrical capacity	12KW
Cost consumption	Total power	13.45KW	16.475KW	17.525KW
	Maximum operating power	11.4KW	11.4KW	11.4KW
	Various components Power	Top brush 0.3KWx1	Top brush 0.3KWx1	Top Brush 0.3KWx1
		Side brush 0.3KWx2	Side brush 0.3KWx2	Side brush 0.3KWx2
		Small brush 0.2KWx2	Small brush 0.2KWx2	Small brush 0.2KWx2
		Conveyor Traveling 0.2KWx2	Conveyor Traveling 0.2KWx2	Conveyor Traveling 0.2KWx2
		Water Pump0.75KWx1	Water Pump 0.75KWx1	Water Pump 0.75KWx1
		Dryer 5.5KWx2	Dryer 5.5KWx2	Dryer 5.5KWx2
			High pressure pump 3KWx1	High pressure pump 4KWx1
			Swing motor 0.025KWx1	Swing motor 0.025KWx3
	Water consumption(one roll over wash)	70L	125L	125L
Wash	Washable car	car, jeep, coach below 9 seats
	Washing ways	1 roll over economy wash	1 roll over economy wash	1 roll over economy wash
		2 roll over standard wash	2 roll over standard wash	2 roll over standard wash
				2 roll over hand wash
	Liquid using	shampoo	shampoo	shampoo
		wax	wax	wax
			FK coating	foam
				FK coating
	Washing time	1 roll over wash: 3mins, 2 roll over wash: 5mins
